Unpacking Procedures
IMPORTANT
Wall Mounted Unit
1. After takeoff the bands and pull out one side cushion, push the unit to the opposite side.
•
2. Pull out the unit from the other side.
Outdoor Unit
1. After takeoff the bands, pull out the carton box from the top side of the unit.
•
* This product is not designed for re-packing. In case of re-packing, contact to Daikin Dealer.
