English 4
Regarding places for installation
•
Is the air conditioner installed at a well-ventilated
place where there are no obstacles around?
• Do not use the air conditioner in the following
places.
a. Filled with much mineral oil such as cutting oil
b. Where there is much salt such as a beach area
c. Where sulfured gas exists such as a hot-spring
resort
d. Where there are considerable voltage fluctua-
tions such as a factory or plant
e. Vehicles and vessels
f. Where there is much spray of oil and vapor
such as a cookery, etc.
g. Where there are machines generating electro-
magnetic waves
h. Filled with acid and/or alkaline steam or vapor
• Is a snow protection measure taken?
For details, consult your dealer.
Regarding wiring
• All wiring must be performed by an authorized
electrician.
To do wiring, ask your dealer. Never do it by yourself.
•
Make sure that a separate power supply circuit
is provided for this air conditioner and that all
electrical work is carried out by qualified per-
sonnel according to local laws and regulations.
Pay attention to running noises, too
• Are the following places selected?
a. A place that can sufficiently withstand the
weight of the air conditioner with less running
noises and vibrations.
b. A place where the hot wind discharged from the air
outlet of the outdoor unit and the running noises.
• Are you sure that there are no obstacles near
the air outlet of the outdoor unit?
Such obstacles may result in declined perfor-
mance and increased running noises.
•
If abnormal noises occur in use, consult your dealer.
Regarding drainage of drain piping
• Is the drain piping executed to perform com-
plete drainage?
If proper drainage is not carried out from the out-
door drain pipes during air-conditioning operation,
chances are that dust and dirt are clogged in the
pipe. This may result in a water leakage from the
indoor unit. Under such circumstances, stop the
operation of the air conditioner, and then consult
your dealer or our service station.
• Operation procedure
Read the operation manual attached to the
remote controller.
4. INSTALLATION SITE
5. OPERATION PROCEDURE
• Operating procedure varies with heat pump type
and cooling only type. Contact your Daikin dealer
to confirm your system type.
• To protect the unit, turn on the main power switch
6 hours before operation.
• If the main power supply is turned off during oper-
ation, operation will restart automatically after the
power turns back on again.
AIR FLOW DIRECTION ADJUST
Press the AIR FLOW DIRECTION button to adjust
the air flow angle.
• The movable limit of the flap is changeable.
Contact your Daikin dealer for details.
Press the AIR FLOW DIRECTION ADJUST but-
ton to select the air direction as shown below.
The AIR FLOW FLAP display
swings as shown below and the
air flow direction continuously
varies. (Automatic swing setting)
Press AIR FLOW DIRECTION
ADJUST button to select the air
direction of your choice.
The AIR FLOW FLAP display
stops swinging and the air flow
direction is fixed (Fixed air flow
direction setting).
MOVEMENT OF THE AIR FLOW FLAP
For the following conditions, micro computer controls the
air flow direction so it may be different from the display.
Operation mode includes automatic operation.
Operation
mode
Cooling Heating
Operation
condition
• When operating
continuously at
horizontal air
flow direction
• When room
temperature is
higher than the
set temperature
•
At defrost operation
(Air is blown
horizontally to prevent
the cool air from being
blown directly onto
anyone in the room.)
Up and down adjustment
swing
