3
1
2
• Split Sky Air • Indoor Units 2
• Indoor Units • R-410A • FCQ-DAV3B
2 Specifications
2-1 TECHNICAL SPECIFICATIONS
FCQ71DAV3B FCQ100DAV3B FC Q125 DAV3B FCQ1 40DAV3B
Casing Colour White
Dimensions Unit Height mm 246 288 288 288
Width mm 840 840 840 840
Depth mm 840 840 840 840
Weight Unit kg 24.0 28.0 28.0 28.0
Heat
Exchanger
Dimensions Nr of Rows 2 2 2 2
Fin Pitch mm 1.20 1.20 1.20 1.20
Face
Area
m² 0.454 0.544 0.544 0.544
Nr of Stages 10 12 12 12
Fin Type Cross fin coil (Multi louver fins and Hi-XSS tubes)
Fan Type Turbo fan
Air Flow Rate Cooling High m³/min 19.0 30.0 30.0 30.0
Low m³/min 14.0 21.0 24.0 25.0
Fan Motor Model QTS46F15M QTS46E17M QTS46E17M QTS46E17M
Output
(high)
W 30 120 120 120
Cooling Sound Power High dBA 50.0 58.0 58.0 58.0
Low dBA 44.0 48.0 51.0 53.0
Sound
Pressure
High dBA 34.0 43.0 43.0 43.0
Low dBA 28.0 33.0 36.0 38.0
Refrigerant Type R-410A
Piping
connections
Liquid (OD) Type Flare connection
Diameter
(OD)
mm 9.5 9.5 9.5 9.5
Gas Type Flare connection
Diameter
(OD)
mm 15.9 15.9 15.9 15.9
Drain Diameter
(OD)
mm I.D. 25/O.D. 32
Decoration
Panel
Model BYCP125DAW1
Colour White
Dimensions H mm 45 45 45 45
W mm 950 950 950 950
D mm 950 950 950 950
Weight kg 5.5 5.5 5.5 5.5
Air Filter Resin net with mold resistance
Safety Devices Low pressure switch Low pressure switch Low pressure switch
High pressure switch
Fuse
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35° CDB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m
In case of drain piping for the outdoor unit, a drain piping kit (option) is needed.
2-2 ELECTRICAL SPECIFICATIONS
FCQ71DAV3B FCQ100DAV3B FC Q125 DAV3B FCQ1 40DAV3B
Power Supply Name V3
Phase 1 1 1 1
Frequency Hz 50 50 50 50
Voltage V 230 230 230 230
