Line in connection

You can connect an external device (like portable player) to the Line in jack of this unit and listen to the

sound through the unit's speakers.

 Insert the audio cable (requires 3.5mm stereo plug, not supplied) into the Line Out Jack or Phones Jack on

external device and into the corresponding Line in Jack on the unit.

 Turn on the unit and slide the Function Selector to AUX position.

 Make sure your AUX in component is turned on, and follow your component’s instruction.

 To stop this function, simply slide the Function Selector to Tape position.

Stereo headphone connecting

 For private listening, insert 3.5 mm headphone into the stereo headphone jack.

 Adjust volume control to the appropriate level as desired.

 When the stereo headphone jack is plugged, speakers will disconnect automatically.

Radio operations

 Slide the function switch to radio position.

 Select the desired band with Band Selector.

 Adjust the Tuning Control to tune in a radio station.

FM and FM stereo reception

 In particular when stereo signal is weak and much noise are received, it is preferable to receive the

program in mono. Slide the band selector to switch between FM stereo and mono modes.

Antenna

 For FM reception, adjust the telescopic antenna appropriately to obtain the best reception on the band

selected.

 The AM signal is picked up through the built-in ferrite antenna. The set should be placed to a position for

the best reception.
