EBHQ006+008BAV3 + EKCBX/H008BAV3
Unit for air to water heat pump system
4PW64603-1A – 08.2010
Operation manual
16
9 Cooling and heating set point ranges
00 Heating set point upper limit 55 37~55 1 °C
01 Heating set point lower limit 25 15~37 1 °C
02 Cooling set point upper limit 22 18~22 1 °C
03 Cooling set point lower limit 5 5~18 1 °C
04 Installation related setting
C Setup on EKRP1HB digital I/O PCB
00 Solar priority mode setting 0 0/1 1 —
01 Installation related setting
02 Installation related setting
03 Installation related setting
04 Installation related setting
d Local shift value weather dependent
00 Installation related setting
01 Installation related setting
02 Installation related setting
03 Local shift value weather dependent 0 0/1/2/3/4 — —
E Unit information readout
00 Software version Read
only
———
01 EEPROM version Read
only
———
02 Unit model identification Read
only
———
03 Liquid refrigerant temperature Read
only
——°C
04 Inlet water temperature Read
only
——°C
F Installation related settings
00 Installation related setting
01 Installation related setting
02 Installation related setting
03 Installation related setting
04 Installation related setting
First
code
Second
code
Setting name
Installer setting at variance with default value
Default
value
Range Step UnitDate Value Date Value
