![Globalsat TR-203 [8/91] Report messages format](/views2/1787713/page8/bg8.png)
7
2.5 Report Messages Format
There are two types of report message format, “format 0” and “format 1”.
(Refer to “11. Report” for detail definition)
Example:
TR-203 -> Server (format 0)
GSr,IMEI,Device_Mode,Report_Type,Alarm_Status,Geofence_st
atus,GPS_Fix,UTC_Date,UTC_Time,Longitude,Latitude,Altitude
,Speed,Heading,Number_of_Satellites,HDOP,Battery_capacity*
checksum!
TR-203 -> Server (format 1)
GSh, IMEI,Alarm_Status,GPS_Fix,Battery_capacity*checksum!
