Pioneer DVH-P4100UB [2/8] What s what

— Press to control SHUFFLEALL

(shuffle all) during iPod playback.

・6/

— Press to control REPEAT (repeat).

9 DISP/BACK/SCRL button

Press to select different displays.

Press and hold to scroll through the

text information.

Press to return to the previous display

when operating the menu.

Press and hold to return to the main

menu when operating the menu.

a /// buttons

Press to perform manual seek tuning,

fast forward, reverse and title/folder/

chapter/track/file search controls.

Press to select a menu on the DVD

menu. Also used for controlling

functions.

・When operating menus

— Pressing  is the same function as

turning MULTI-CONTROL right.

— Pressing  is the same function as

turning MULTI-CONTROL left.

— Pressing  is the same function as

pressing DISP/BACK/SCRL.

— Pressing and holding  is the

same function as pressing and

holding DISP/BACK/SCRL.

— Pressing  is the same function as

pressing MULTI-CONTROL.

・When operating lists

— Pressing  is the same function as

turning MULTI-CONTROL left.

— Pressing  is the same function as

turning MULTI-CONTROL right.

— Pressing  is the same function as

pressing DISP/BACK/SCRL.

— Pressing and holding  is the

same function as pressing and

holding DISP/BACK/SCRL.

— Pressing  is the same function as

pressing MULTI-CONTROL.

— Pressing and holding  is the

same function as pressing and

holding MULTI-CONTROL.

b BAND/ESC button

Press to select among two FM bands

and MW/LW bands.

Press to return to the ordinary display

when operating the menu.

Note

・ The function of DISP/BACK/SCRL

is different depending on the setting

of the display connection (refer to the

Operation Manual).

DVD operation

1 SRC/OFF button

This unit is turned on by selecting a

source. Press to cycle through all the

available sources.

2 MULTI-CONTROL

Turn to increase or decrease the

volume. Press to select a menu on the

DVD menu. Also used for controlling

functions.

3 LIST/ button

Press to display the track title list,

folder list or file list depending on the

source.

Press and hold to turn the link play on

during iPod playback.

・ This button is not effective when

tuner is selected as a source.

4 USB port

Use to connect a USB audio player/USB

memory and iPod.

・ When connecting, open up the USB

connector lid.

・ Use a USB cable to connect the USB

audio player/USB memory to the USB

port. Since the USB audio player/USB

memory is projected forward from

the unit, it is dangerous to connect

directly. Pioneer CD-U50E USB cable

is also available. For details, consult

your dealer.

5 button

Press to open the front panel.

6 AUX input jack (3.5 mm stereo

jack)

Use to connect an auxiliary device.

・ You can connect an auxiliary video

device and an iPod with video

compatibility.

7 TA/AF button

Press to turn TA function on or off.

Press and hold to turn AF function on

or off.

8 1/S.Rtrv to 6/ buttons

Press for preset tuning. Also used for

controlling functions.

・ 1/S.Rtrv

— Press to control S.RTRV

(advanced sound retriever).

・ 2/PAUSE

— Press to control PAUSE (pause).

・4/iPod

— Press to control CTRL (control

mode) during iPod playback.

・5/

— Press to control RANDOM

(random).

What’s what

Return to the top menu

during DVD playback

Display the DVD menu

during DVD playback

Select a menu on

the DVD menu

Select a menu on the DVD

Switch between playback

and pause

Stop playback

Return to the previous

chapter

Go to the next chapter

First, set this operation mode switch to DVD

For details, refer to the Operation Manual

Select a chapter

Select a title
