Zanussi FCS 825C [12/48] Care and cleaning
![Zanussi FCS 825C [12/48] Care and cleaning](/views2/1049721/page12/bgc.png)
Programme/ Temperature Type of laundry Available options
Description of the pro-
gramme
SPIN
Separate spin for hand
washed garments and after
programmes with the Rinse
Hold option selected. You
can choose the spin speed
by turning the spin speed
selector to adapt it to the
fabrics to be spun.
SPIN REDUCTION
Drain and long spin
Max. spin speed 800 rpm
Max Load 3 kg
/OFF
For resetting the pro-
gramme or switching the
machine off
1) If you select this option, we recommend that you reduce the maximum load. Recommended load for cotton is 2 kg. This option
cannot be selected together with Economy option.
2) Available at the temperature 60° and 40°.
3) Available at the temperature 60°.
Care and cleaning
Important! You must DISCONNECT the appliance from the
electricity supply, before you can carry out any cleaning or
maintenance work.
Descaling
The water we use normally contains lime. It is a good idea
to periodically use a water softening powder in the ma-
chine. Do this separately from any laundry washing, and
according to the softening powder manufacturer's instruc-
tions. This will help to prevent the formation of lime de-
posits.
Maintenance Wash
With the use of low temperature washes it is possible to
get a build up of residues inside the drum.
We recommend that a maintenance wash be performed on
a regular basis.
To run a maintenance wash:
• The drum should be empty of laundry.
• Select the hottest cotton wash programme.
• Use a normal measure of detergent, must be a powder
with biological properties.
External cleaning
Clean the exterior cabinet of the appliance with soap and
water only, and then dry thoroughly.
Cleaning the dispenser drawer
The washing powder and additive dispenser drawer
should be cleaned regularly.
If necessary, the whole de-
tergent drawer can be tak-
en out of the machine for
cleaning. You need to pull
it firmly outwards, so that
it comes free of retaining
stop.
To remove the siphon at
the inside edge of the
drawer for cleaning, you
need to press it inwards
and pull it upwards at the
same time. Flush it out
under a tap, to remove any
traces of accumulated
powder.
When you put it back, press it downwards until you hear a
distinct click.
12
