Viconte VC-4300 [6/11] Self cleaning

SELF-CLEANING



It is important to apply the self-cleaning function at least every two weeks to remove scale deposit.

 The harder the water the more often the iron should be self-cleaned.

 Fill water reservoir up to the maximum level and then close it.



Set the temperature control to its maximum position “ MAX ” .



Insert the main plug into the wall socket.



Allow the iron to heat up until the indicator light goes out.



Holding the iron horizontally over the sink then set the variable steam control into position “ 3 ” and press the self-

cleaning button.



Boiling water and steam will be ejected from the holes in soleplate with Impurities washed out. Rock the iron forwards

and backwards during this operation.



Set the steam control to the minimum position “ 0 ” after emptying the water reservoir.



Repeat self-cleaning if you notice that much impurity has been washed out.



Move the iron over an old (preferably) piece of cloth. This to ensure that the soleplate will be dry during storage.



Unplug and allow the iron to cool down before storing it.

STORAGE



Empty the water tank then wrap the cord around the heel rest.



To protect the soleplate, store the iron in an upright position on its heel rest.

SPECIFICATION

Power supply

230 V, 50 Hz

Power

1800 W

Net/Gross Weight

1.12 kg / 1.32 kg

Gift box dimension ( L x W x H )

300 mm x 135 mm x 160 mm
