Front Panel

SIDE KEYPAD AND FRONT PANEL

Power/Standby Indicator: Blue and red dual-color LED. It shows red when the TV is turned off and blue when

turned on.

Remote Control Sensor: Remote control IR sensor, which receives infrared ray sent by remote control.

1. POWER (

) /OK: In the off mode, Short press to turn on the TV. In the on mode, Short press to achieve OK

function, long press to achieve POWER function.

POWER ( ): Turns the TV on and off.

OK: Enter and conﬁrm.

2. VOL-: Decreases the volume. In the TV menu system, it acts like the left arrow on the remote control and can be

used to select menu options.

3. VOL+: Increases the volume. In the TV menu system, it acts like the right arrow on the remote control and can be

used to select menu options.

4. MENU/CH-: Short press to achieve CH- function, long press to achieve MENU function.

MENU: Displays the TV Main Menu.

CH-: Scans down through the channel list. In the TV menu system, it acts like the down arrow on the remote

control and can be used to select menu options.

5. INPUT/CH+: Short press to achieve CH+ function, long press to achieve INPUT function.

INPUT: Displays the Source Select List.

CH+: Scans up through the channel list. In the TV menu system, it acts like the up arrow on the remote control

and can be used to select menu options.

Power/Standby Indicator

Remote Control Sensor
