![Nissan Note [21/22] Trouble diagnosis](/views2/1789827/page21/bg15.png)
TROUBLE DIAGNOSIS
STC-21
[EPS]
C
D
E
F
H
I
J
K
L
M
A
B
STC
Symptom 2: There is a Difference in the Steering Turning/Returning Force of
Left and Right (Biased to One Side)
BGS0003G
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Are there malfunctioning systems in self-diagnosis results?
YES >> GO TO 2.
NO >> GO TO 4.
2. CHECK EPS CONTROL UNIT CONNECTOR
1. Turn ignition switch OFF, disconnect EPS control unit harness connector, and check terminal for deforma-
tion, disconnection, looseness, etc.
2. Reconnect harness connector securely, and perform self-diagnosis.
Are there malfunctioning systems in self-diagnosis results?
YES >> Repair malfunctioning circuit, and GO TO3.
NO >> GO TO 3.
3. CHECK SYMPTOM
Make sure that the steering does not have the symptoms of “Heavy” or “Light”.
OK or NG
OK >> INSPECTION END.
NG >> GO TO 4.
4. WHEEL ALIGNMENT INSPECTION
Check wheel alignment. Refer to FSU-6, "
Wheel Alignment" .
OK or NG
OK >> Check steering wheel turning force. Refer to PS-5, "STEERING TORQUE INSPECTION" .
NG >> Adjust wheel alignment. Refer to FSU-6, "
Wheel Alignment" .
Symptom 3: Steering Wheel Turning Force is Uneven (Torque Variation)
BGS0003H
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Are there malfunctioning systems in self-diagnosis results?
YES >> GO TO 2.
NO >> GO TO 4.
2. CHECK EPS CONTROL UNIT CONNECTOR
1. Turn ignition switch OFF, disconnect EPS control unit harness connector, and check terminal for deforma-
tion, disconnection, looseness, etc.
2. Reconnect harness connector securely, and perform self-diagnosis.
Are there malfunctioning systems in self-diagnosis results?
YES >> Repair malfunctioning circuit, and GO TO 3.
NO >> GO TO 3.
3. CHECK SYMPTOM
Make sure that the steering does not have the symptoms of “Heavy” or “Light”.
OK or NG
OK >> INSPECTION END.
NG >> GO TO 4.
