English 5
• Are you sure that there are no obstacles near
the air outlet of the outdoor unit?
Such obstacles may result in declined
perfor
mance and increased running noises.
• If abnormal noises occur in use, consult your
dealer.
Regarding drainage of drain piping
• Is the drain piping executed to perform
complete drainage?
Refer to figure 1 on page [1]
The illustrations in this operating manual
correspond
to the remote control format BRC1C type.
5.
NAME AND FUNCTION OF EACH
SWITCH
AND DISPLAY ON THE
REMOTE CONTROLLER
1
ON/OFF BUTTON
Press the button and the system will start.
Press the button again and the system will stop.
2
OPERATION LAMP (RED)
The lamp lights up during operation.
3
DISPLAY “ ”
(UNDER CENTRALIZED CONTROL)
When this display shows, the system is
UNDER CENTRALIZED CONTROL.
(This is not a standard specification)
4
DISPLAY “ ” “ ” “ ” “ ” “ ”
(OPERATION MODE)
This display shows the current OPERATION
MODE.
5
DISPLAY “
TEST
” (INSPECTION/TEST
OPERATION)
When the INSPECTION/TEST OPERATION
BUTTON is pressed, the display shows that
this mode is operation.
6
DISPLAY “ ” (PROGRAMMED TIME)
This display shows the PROGRAMMED TIME
of the system start or stop.
7
DISPLAY “ ” (SET TEMPERATURE)
This display shows the set temperature.
hr
hr
C
01_EN_3PN07753-14T.fm Page 5 T hursday, January 13, 2011 3:54 PM
c. Where there is much salt such as a beach area
d. Where sulfured gas exists such as a hot-spring
resort
e. Where there are considerable voltage
fluctuations such as a factory or plant
f . Vehicles and vessels
g. Where there are machines generating
electromagnetic waves
h. Filled with acid and/or alkaline steam or vapor
• Is a snow protection measure taken?
For details, consult your dealer.
Regarding wiring
• All wiring must be performed by an authorized
electrician.
To do wiring, ask your dealer. Never do it by yourself.
• Make sure that a separate power supply circuit
is provided for this air conditioner and that all
electrical work is
carried out by qualified
per
sonnel according to local laws and
regulations.
Pay attention to running noises, too
• Are the following places selected?
a. A place that can sufficiently withstand the
weight of the air conditioner with less running
noises and vibrations.
b. A place where the hot wind discharged from the
air outlet of the outdoor unit and the running
noises.
8
DISPLAY “ ” (FAN SPEED)
This display shows the set fan speed.
9
DISPLAY “ ” (TIME TO CLEAN AIR
FIL
TER) <FILTER : OPTION PARTS>
Refer to “HOW TO CLEAN THE AIR FILTER”.
10
DISPLAY “ ” (DEFROST)
Refer to “DEFROST OPERATION”.
11
NON-FUNCTIONING DISPLAY
If that particular function is not available,
pressing the button may display the words
“NOT AVAILABLE” for a few seconds.
When running multiple units simultaneously,
the “NOT AVAILABLE” message will only be
appear if none of the indo
or units is equipped
with the function. If even one unit is equipped
with the function, the display will not appear.
System relocation
●
Consult your Daikin dealer about remodelling
and relocation.
If proper drainage is not carried out from the out-
door drain pipes during air-conditioning operation,
chances are that dust and dirt are clogged in the
pipe. This may result in a water leakage from the
indoor unit. Under such circumstances, stop the
operation of the air conditioner, and then consult
your dealer or our service station.
