put the telescopic suction tube into the operating
position as required (depending on the height of the
user) by pressing the button “A” and shifting the tube
sections in direction as shown by the arrows,
A
install an appropriate tool e.g. the suction-brush onto
the other end of the suction tube,
draw the cord (5) out of the vacuum cleaner body and put
the plug into a network socket,
66
Pay attention, while drawing the cord out, to a yellow
band on the cord which means the end of the cord.
Put the vacuum cleaner into operation by pressing the
button
on the vacuum cleaner (6) and choose the
suitable suction power using the buttons
or .
SUCTION POWER REGULATION
The vacuum cleaner is equipped with an electronic suction power regulator which makes it possible to
set the suction power gradually. The suction power regulation can be carried out by using two buttons
(
, ): consecutive power stages are being communicated by respective LEDS burning. Pressing a
button according to its markings
or results into the suction power getting increased or
decreased.
Putting the vacuum cleaner into operation
by using the power switch does set the
operation of the suction unit onto the third
stage of suction power regulation:
3 LEDS on the 5-stage-led-bar are
burning.
We do recommend the following settings:
1-st stage to vacuum curtains
2-nd stage to vacuum upholstery
3-rd stage means cost-effective power
4-th stage to vacuum carpets
5-th stage to vacuum hard floors and
crevices
The vacuum cleaners are equipped also with a mechanic suction power
regulation on the hose handle. In order to decrease the suction power it is
enough to shift the valve as indicated in the drawing.
HOW THE BAG FULL INDICATOR WORKS
If the bag full indicator turns red with the nozzle or the brush raised over the
surface being vacuumed, that means that the bag has to be emptied.
The bag full indicator can trip when the suction hose and the elements connected to it have got
clogged. In such a case you have to take the hose end out of the front cover hole and clean the hose
and the elements connected to it.
HOW THE OUTLET FILTER EXCHANGE INDICATOR WORKS
The HEPA outlet air filter has to be exchanged after it has been used for about one year, when the
surface of the filter is dirty. If the outlet filter exchange indicator gets red (pulsating red color) this
means that it is necessary to exchange the filter.
At the same time the outlet filter exchange acoustic alarm, so called “buzzer”, is tripping, the suction
power of the vacuum cleaner is falling to stage 1 as well. Of course you can finish the vacuuming on
the required suction power by pressing on the button
which will increase the suction power.
6
5
Ba
g
full indicator
Winder
button
Switch
button
Suction power
regulation button
Electro-brush
socket
Outlet filter
exchange indicator
“Auto-reverse”
slide
Suction power
regulation button
