RXD-M57MP
25
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
IC201 UPC1330HA IC(2CH HEAD SWITCHING)0-00
IC202 TA8142AP IC TA8142AP Tos03-08142-00
IC301 TC9422F IC TC9422F Tosh03-09422-00
IC302 NJM7812A IC NJM7812A ‘JR03-07812-00
IC401 ✻ LM4809MM IC LM4809MM MSO03-04809-00
IC402 STK402-030 IC(2CH AF POWER AMP)020-00
IC501 RPM6938-V4 Sensor RPM6938-02-66938-00
IC601 ✻ 87EP26F-4K76 CPU TMP 87EP 03-87261-00
IC700 ✻ TC94A02F-007 IC TC94A02F-00703-09402-01
IC701 TC9462F IC TC9462F 03-09462-00
IC702 TA7291S IC(BRIDGE DRIVER)-07291-00
IC703 TA2092N IC TA2092N Tosh03-02092-00
IC704 TA2153FN IC TA2153FN Tos03-02153-00
IC705 ✻ AS7C31024-15 IC AS7C31024-1503-31024-00
IC706 ✻ MC74HC14AD IC MC74HC14AD 03-07414-01
IC707 NJM7805FA IC(VOLTAGE REGULATOR)05-02
ICP900 ICP-N20 IC(PROTECT)r IC03-00020-00R
Q101 ✻ 9018 Transistor 901801-09018-10
Q102,103 8550 Transistor 855001-08550-06
Q104 9014 Transistor 901401-09014-05 E
Q105-107 9013G Transistor 901301-09013-11B
Q109-112 9013G Transistor 901301-09013-11B
Q113 8550 Transistor 855001-08550-06
Q114 9013G Transistor 901301-09013-11B
Q115 9014 Transistor 901401-09014-05
Q204 9013G Transistor 901301-09013-11B
Q205 8050 Transistor 805001-08050-06
Q208 8050 Transistor 805001-08050-06
Q209 9013G Transistor 901301-09013-11B
Q210 8050 Transistor 805001-08050-06
Q211 8550 Transistor 855001-08550-06
Q212-214 9013G Transistor 901301-09013-11B
Q215 8550 Transistor 855001-08550-06
Q216,217 9013G Transistor 901301-09013-11B
Q301,302 9014 Transistor 901401-09014-05
Q303,304 2SC1383R Transistor 2SC101-01383-18B
Q404 9013G Transistor 901301-09013-11B
Q408,409 8050 Transistor 805001-08050-06
Q412 9013G Transistor 901301-09013-11B
Q415 9013G Transistor 901301-09013-11B
Q416 8550D Transistor 855001-08550-05B
Q425-427 8050 Transistor 805001-08050-06
Q428 8550D Transistor 855001-08550-05B
Q601 9013G Transistor 901301-09013-11B
Q603 9013G Transistor 901301-09013-11B
Q604 8550D Transistor 855001-08550-05B
Q605,606 9013G Transistor 901301-09013-11B
Q607 8550D Transistor 855001-08550-05B
Q608 8550 Transistor 855001-08550-06
Q609 9013G Transistor 901301-09013-11B
Q703,704 8050 Transistor 805001-08050-06
Q705 8550 Transistor 855001-08550-06
Q706-708 8050 Transistor 805001-08050-06
Q709 8550 Transistor 855001-08550-06
Q710-712 8050 Transistor 805001-08050-06
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
#
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R754 RK73GB1J225J CHIP R 2.2M J 1/16W
R755 RK73GB1J103J CHIP R 10K J 1/16W
R757,758 RK73GB1J271J CHIP R 270 J 1/16W
R760-772 RK73GB1J103J CHIP R 10K J 1/16W
R774-780 RK73GB1J103J CHIP R 10K J 1/16W
R781 RK73GB1J102J CHIP R 1.0K J 1/16W
R782 RK73GB1J273J CHIP R 27K J 1/16W
R783 RK73GB1J222J CHIP R 2.2K J 1/16W
R784 RK73GB1J473J CHIP R 47K J 1/16W
R785 RK73GB1J221J CHIP R 220 J 1/16W
R786 RK73GB1J823J CHIP R 82K J 1/16W
R787,788 RK73GB1J103J CHIP R 10K J 1/16W
R789 RK73GB1J823J CHIP R 82K J 1/16W
R790 RK73GB1J100J CHIP R 10 J 1/16W
R791-794 RK73GB1J103J CHIP R 10K J 1/16W
R799 RK73GB1J562J CHIP R 5.6K J 1/16W
R800,801 RK73GB1J103J CHIP R 10K J 1/16W
R802 RK73GB1J104J CHIP R 100K J 1/16W
R803 RK73GB1J102J CHIP R 1.0K J 1/16W
R805 RD14BB2H100J RD 10 J 1/2W
R806 RK73GB1J221J CHIP R 220 J 1/16W
R807,808 RK73GB1J102J CHIP R 1.0K J 1/16W
R810 RK73GB1J222J CHIP R 2.2K J 1/16W
R811 RK73GB1J153J CHIP R 15K J 1/16W
R813 RK73GB1J103J CHIP R 10K J 1/16W
R814 RK73GB1J221J CHIP R 220 J 1/16W
R815-817 RK73GB1J220J CHIP R 22 J 1/16W
R818,819 RK73GB1J123J CHIP R 12K J 1/16W
R823-825 RK73GB1J103J CHIP R 10K J 1/16W
R826 RS14GB3A101J FL-PROOF RS 100 J 1W
R908,909 ✻ R92-4676-08 FL-PROOF RS 220 J 5W
RL401 ✻ S76-0145-08 Lead Free Relay16-50212-00
RL901 ✻ S76-0144-08 Relay Switch SD16-50101-01
SW19 ✻ T99-0694-08 E.L Volume 162118-72102-01
SW500-517
✻ S70-0116-08 Tact Switch EVQ16-10101-08C
SW900 ✻ S62-0124-08 Voltage SW. SL116-10212-00 M
D101-104 1SS133 Diode 1SS-133TP02-00133-00
D105 SVC348T Tuning Diode SV02-00348-01
D106 1SS133 Diode 1SS-133TP02-00133-00
D108 1SS133 Diode 1SS-133TP02-00133-00
D201 1SS133 Diode 1SS-133TP02-00133-00
D401 1SS133 Diode 1SS-133TP02-00133-00
D409-411 1SS133 Diode 1SS-133TP02-00133-00
D601,602 1N4148 Diode 1N4148 02-04148-00W
D603 1SS133 Diode 1SS-133TP02-00133-00
D604-608 1N4148 Diode 1N4148 02-04148-00W
D702,703 1SS133 Diode 1SS-133TP02-00133-00
D901-908 1N4001 Diode 1N4001 02-04001-00
D909-912 1N5402 Diode 1N5402-F 02-05402-00
D913-916 1N4001 Diode 1N4001 02-04001-00
D917 1N4148 Diode 1N4148 02-04148-00W
IC101 TA2099N IC(AM/FM SYSTEM IC)2099-00
IC102 TC9257F IC TC9257F 03-09257-01
IC103 BU1923F RDS Demodulator03-01923-00 E
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
!
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
