Gigabyte GA-8I915P Dual Graphic Руководство пользователя онлайн
GA-8I915P Dual Graphic
Intel
®
Pentium
®
4 LGA775 Processor Motherboard
User's Manual
Rev. 1002
12ME-8I915PDG-1002
Содержание
- Ga 8i915p dual graphic 1
- User s manual 1
- Copyright 3
- Notice 3
- Product manual classification 3
- Chapter 1 hardware installation 9 4
- Chapter 2 bios setup 31 4
- Ga 8i915p dual graphic motherboard layout 6 block diagram 7 4
- Table of contents 4
- Chapter 3 install drivers 51 5
- Chapter 4 appendix 55 5
- Ga 8i915p dual graphic 6
- Ga 8i915p dual graphic motherboard layout 6
- Block diagram 7
- 1 considerations prior to installation 9
- Chapter 1 hardware installation 9
- English 9
- Installation notices 9
- Instances of non warranty 9
- Preparing your computer 9
- 2 feature summary 10
- English 10
- English 11
- 3 1 installation of the cpu 12
- 3 installation of the cpu and heatsink 12
- English 12
- 3 2 installation of the heatsink 13
- English 13
- 4 installation of memory 14
- English 14
- Dual channel ddr ddr ii 15
- English 15
- 5 installation of expansion cards 16
- English 16
- 6 configuring a quad view system 17
- English 17
- English 18
- 7 i o back panel introduction 19
- Back surround speaker out 19
- Com a serial port 19
- English 19
- Lan port 19
- Line in 19
- Line out front speaker out 19
- Mic in 19
- Parallel port 19
- Ps 2 keyboard and ps 2 mouse connector 19
- Spdif_i spdif in 19
- Spdif_o spdif out 19
- Usb port 19
- 8 connectors introduction 20
- Center subwoofer speaker out 20
- English 20
- Surround speaker out 20
- 2 atx_12v atx power connector 21
- English 21
- Hardware installation 21 21
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector please make sure that all components and devices are properly installed align the power connector with its proper location on the motherboard and connect tightly the atx_12v power connector mainly supplies power to the cpu if the atx_12v power connector is not connected the system will not start caution please use a power supply that is able to handle the system voltage requirements it is recommended that a power supply that can withstand high power consumption be used 300w or greater if a power supply is used that does not provide the required power the result can lead to an unstable system or a system that is unable to start if you use a 24 pin atx power supply please remove the small cover on the power connector on the motherboard before plugging in the power cord otherwise please do not remove it 21
- 4 5 cpu_fan sys_fan pwr_fan cooler fan power connector 22
- Cpu_fan 22
- English 22
- Ga 8i915p dual graphic motherboard 22 22
- If you installed wrong direction the chip fan will not work sometimes will damage the chip fan usually black cable is gnd 22
- Nb_fan chip fan connector 22
- Pwr_fan 22
- Sys_fan 22
- The cooler fan power connector supplies a 12v power voltage via a 3 pin 4 pin only for cpu_fan power connector and possesses a foolproof connection design most coolers are designed with color coded power connector wires a red power connector wire indicates a positive connection and requires a 12v power voltage the black connector wire is the ground wire gnd please remember to connect the power to the cooler to prevent system overheating and failure caution please remember to connect the power to the cpu fan to prevent cpu overheating and failure 22
- 9 ide1 ide2 ide3 ide connector 23
- An ide device connects to the computer via an ide connector one ide connector can connect to one ide cable and the single ide cable can then connect to two ide devices hard drive or optical drive if you wish to connect two ide devices please set the jumper on one ide device as master and the other as slave for information on settings please refer to the instructions located on the ide device to ensure that an ide cd rom drive can work properly please attach it to the ide 1 connector 23
- English 23
- Fdd floppy connector 23
- Hardware installation 23 23
- The fdd connector is used to connect the fdd cable while the other end of the cable connects to the fdd drive the types of fdd drives supported are 360kb 720kb 1 mb 1 4mb and 2 8mb please connect the red power connector wire to the pin1 position 23
- English 24
- Ga 8i915p dual graphic motherboard 24 24
- Pwr_led 24
- Pwr_led is connect with the system power indicator to indicate whether the system is on off it will blink when the system enters suspend mode 24
- Sata0 sata1 sata2 sata3 serial ata connector 24
- Serial ata can provide 150mb s transfer rate please refer to the bios setting for the serial ata and install the proper driver in order to work properly 24
- English 25
- F_panel front panel jumper 25
- Hardware installation 25 25
- Please connect the power led pc speaker reset switch and power switch etc of your chassis front panel to the f_panel connector according to the pin assignment below 25
- Azalia_fp front audio panel connector 26
- Cd_in cd in 26
- Connect cd rom or dvd rom audio out to the connector 26
- English 26
- Ga 8i915p dual graphic motherboard 26 26
- Hd audio is the default setting for this connector to enable ac 97 audio from bios settings set front panel type under integrated peripherals to ac97 26
- This connector is supported to connect hd high definition audio and ac 97 audio check the pin assignment carefully while you connect the audio panel cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional audio panel cable please contact your local dealer 26
- Be careful with the polarity of the front usb connector check the pin assignment carefully while you connect the front usb cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional front usb cable please contact your local dealer the usb device wake up from s3 is only supported by rear usb ports 27
- English 27
- F1_1394 27
- F1_1394 f2_1394 ieee 1394 connector 27
- F2_1394 27
- F_ usb1 f_usb2 front usb connector 27
- Hardware installation 27 27
- Serial interface standard set by institute of electrical and electronics engineers which has features like high speed high bandwidth and hot plug be careful with the polarity of the ieee1394 connector check the pin assignment carefully while you connect the ieee1394 cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional ieee1394 cable please contact your local dealer 27
- Be careful with the polarity of the ir connector while you connect the ir please contact your nearest dealer for optional ir device 28
- Clr_cmos clear cmos 28
- English 28
- Ga 8i915p dual graphic motherboard 28 28
- You may clear the cmos data to its default values by this jumper to clear cmos temporarily short 1 2 pin default doesn t include the shunter to prevent from improper use this jumper 28
- Bat battery 29
- English 29
- Hardware installation 29 29
- If you want to use the pcie_1 slot set all of the four pins to off 29
- If you want to use the pcie_16_2 slot or enable the dual graphic fuction set all of them to on 29
- Sw1 dual graphic dip switch 29
- English 30
- Chapter 2 bios setup 31
- Control keys 31
- English 31
- Main menu 31
- Status page setup menu option page setup menu 31
- Advanced bios features 32
- English 32
- Fail safe defaults indicates the value of the system parameters which the system would be in safe configuration 32
- Ga 8i915p dual graphic motherboard 32 32
- If you can t find the setting you want please press ctrl f1 to search the advanced option hidden please load optimized defaults in the bios when somehow the system works not stable as usual this action makes the system reset to the default for stability 32
- Integrated peripherals 32
- Load fail safe defaults 32
- Mb intelligent tweaker m i t 32
- Pc health status 32
- Pnp pci configuration 32
- Power management setup 32
- Standard cmos features 32
- The main menu for example bios ver f1 32
- This setup page includes all onboard peripherals 32
- This setup page includes all the configurations of pci pnp isa resources 32
- This setup page includes all the items in standard compatible bios 32
- This setup page includes all the items of award special enhanced features 32
- This setup page includes all the items of green function features 32
- This setup page is control cpu clock and frequency ratio 32
- This setup page is the system auto detect temperature voltage fan speed 32
- To accept or enter the sub menu 32
- English 33
- 1 standard cmos features 34
- Access mode use this to set the access mode for the hard drive the four options are chs lba large auto default auto hard drive information should be labeled on the outside drive casing enter the appropriate option based on this information 34
- Cylinder number of cylinders 34
- Day the day from 1 to 31 or the maximum allowed in the month 34
- English 34
- Ga 8i915p dual graphic motherboard 34 34
- Head number of heads 34
- Ide channel 0 master slave 34
- Ide hdd auto detection press enter to select this option for automatic device detection ide channel 0 master slave ide device setup you can use one of three methods auto allows bios to automatically detect ide devices during post default none select this if no ide devices are used and the system will skip the automatic detection step and allow for faster system start up manual user can manually input the correct settings 34
- Landing zone landing zone 34
- Month the month jan through dec 34
- Precomp write precomp 34
- The time is calculated base on the 24 hour military time clock for example 1 p m is 13 00 00 34
- Week the week from sun to sat determined by the bios and is display only 34
- Year the year from 1999 through 2098 34
- Base memory 35
- Drive a drive b 35
- English 35
- Extended memory 35
- Floppy 3 mode support for japan area 35
- Halt on 35
- Memory 35
- Total memory 35
- 2 advanced bios features 36
- Cdrom select your boot device priority by cdrom 36
- Disabled select your boot device priority by disabled 36
- English 36
- First second third boot device 36
- Floppy select your boot device priority by floppy 36
- Ga 8i915p dual graphic motherboard 36 36
- Hard disk boot priority 36
- Hard disk select your boot device priority by hard disk 36
- Lan select your boot device priority by lan 36
- Ls120 select your boot device priority by ls120 36
- Note this item will show up when you install a processor which supports this function 36
- Pentiu 36
- Processor with ht technology 36
- Select boot sequence for onboard or add on cards scsi raid etc 36
- System will detect automatically and show up when you install the inte 36
- To exit this menu 36
- Usb cdrom select your boot device priority by usb cdrom 36
- Usb fdd select your boot device priority by usb fdd 36
- Usb hdd select your boot device priority by usb hdd 36
- Usb zip select your boot device priority by usb zip 36
- Zip select your boot device priority by zip 36
- Cpu enhanced halt c1e 37
- Cpu hyper threading 37
- Cpu thermal monitor 2 tm2 37
- English 37
- Init display first 37
- Limit cpuid max to 3 37
- No execute memory protec 37
- Password check 37
- 3 integrated peripherals 38
- Ahci support hotplug function under os winxp 2000 only 38
- Disabled disable onboard 1st channel ide port 38
- Disabled select onboard seria ata function as ata 38
- Enabled enable onboard 1st channel ide port default value 38
- English 38
- Ga 8i915p dual graphic motherboard 38 38
- On chip primary pci ide 38
- Raid select onboard seria ata function as raid default value 38
- Sata raid ahci mode 38
- Azalia codec 39
- English 39
- Front panel type 39
- On chip sata mode 39
- Pata ide set to 39
- Sata port 0 2 set to 39
- Sata port 1 3 set to 39
- Usb 2 controller 39
- Usb controller 39
- Usb keyboard support 39
- Usb mouse support 39
- English 40
- Onboard h w 1394 40
- Onboard h w lan 40
- Onboard h w raid 40
- Onboard irda port 40
- Onboard lan boot rom 40
- Onboard serial port 1 40
- Uart mode select 40
- Ur2 duplex mode 40
- Ecp mode use dma 41
- English 41
- Onboard parallel port 41
- Parallel port mode 41
- 4 power management setup 42
- Acpi suspend type 42
- Date of month alarm everyday 1 31 42
- Delay 4 sec press power button 4 sec to power off enter suspend if button is pressed less than 4 sec 42
- Disabled disable power on by ring function 42
- Disabled disable this function 42
- Disabled disable this function default value 42
- Double click double click on ps 2 mouse left button to power on the system 42
- Enabled enable alarm function to power on system if rtc alarm lead to power on is enabled 42
- Enabled enable pme event wake up default value 42
- Enabled enable power on by ring function default value 42
- English 42
- Ga 8i915p dual graphic motherboard 42 42
- Instant off press power button then power off instantly default value 42
- Pme event wake up 42
- Power on by mouse 42
- Power on by ring 42
- Resume by alarm 42
- S1 pos set acpi suspend type to s1 pos power on suspend default value 42
- S3 str set acpi suspend type to s3 str suspend to ram 42
- Soft off by pwr bttn 42
- Time hh mm ss alarm 0 23 0 59 0 59 42
- You can set resume by alarm item to enabled and key in date time to power on system 42
- Ac back function 43
- English 43
- Kb power on password 43
- Power on by keyboard 43
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 1 44
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 2 44
- 4 5 7 9 10 11 12 14 15 set irq 3 4 5 7 9 10 11 12 14 15 to pci 3 44
- 5 pnp pci configurations 44
- Auto auto assign irq to pci 1 default value 44
- Auto auto assign irq to pci 2 default value 44
- Auto auto assign irq to pci 3 default value 44
- English 44
- Ga 8i915p dual graphic motherboard 44 44
- Pci 1 irq assignment 44
- Pci 2 irq assignment 44
- Pci 3 irq assignment 44
- 6 pc health status 45
- Cpu power system fan fail warning 45
- Cpu smart fan control 45
- Cpu warning temperature 45
- Current cpu power system fan speed rpm 45
- Current cpu temperature 45
- Current voltage v vcore ddrv 3 v 12v 45
- English 45
- 7 mb intelligent tweaker m i t 46
- Auto bios autodetects the type of cpu fan you installed and sets the optimal cpu smart fan control mode for it default value 46
- Auto set robust graphics booster to auto default value 46
- C i a cpu intelligent acelerator 2 is designed to detect cpu loading during software program executing and automatically adjust cpu computing power to maximize system performance 46
- Cpu clock ratio 46
- Cpu smart fan mode 46
- Cruise set c i a to cruise automatically increase cpu frequency 5 7 by cpu loading 46
- Disabled disable this function default value 46
- English 46
- Fast set robust graphics booster to fast 46
- Ga 8i915p dual graphic motherboard 46 46
- Incorrect using these features may cause your system broken for power end user use only 46
- Pwm set to pwm when you use a cpu fan with a 4 pin fan power cable note in fact the voltage option can be used for cpu fans with 3 pin or 4 pin power cables however some 4 pin cpu fan power cables are not designed following intel 4 wire fans pwm control specifications with such cpu fans selecting pwm will not effectively reduce the fan speed 46
- Robust graphics booster 46
- Select the options can enhance the vga graphics card bandwidth to get higher performance 46
- This option is available only when cpu smart fan control is enabled 46
- This setup option will automatically assign by cpu detection the option will display locked and read only if the cpu ratio is not changeable 46
- Turbo set robust graphics booster to turbo 46
- Voltage set to voltage when you use a cpu fan with a 3 pin fan power cable 46
- Cpu host clock control 47
- Cpu host frequency mhz 47
- Dimm overvoltage control 47
- English 47
- Memory frequency for 47
- Memory frequency mhz 47
- Pci experss frequency mhz 47
- 0 v set dimm overvoltage control to 0 v incorrect using it may cause your system broken for power end user use only 48
- 0 v set fsb overvoltage control to 0 v 48
- 0 v set pci e overvoltage control to 0 v 48
- 8 load fail safe defaults 48
- Cpu voltage control 48
- Display your cpu vcore voltage 48
- English 48
- Fail safe defaults contain the most appropriate values of the system parameters that allow minimum system performance 48
- Fsb overvoltage control 48
- Ga 8i915p dual graphic motherboard 48 48
- Normal cpu vcore 48
- Normal set fsb overvoltage control to normal default value 48
- Normal set pci e overvoltage control to normal default value 48
- Pci e overvoltage control 48
- Supports adjustable cpu vcore from 0 375v to 1 000v default value normal warning cpu may be damaged or reduce cpu life cycle when cpu is over voltage 48
- 10 set supervisor user password 49
- 9 load optimized defaults 49
- Bios setup 49 49
- English 49
- Selecting this field loads the factory defaults for bios and chipset features which the system automatically detects 49
- When you are prompted to enter password a message password disabled will appear to confirm the password being disabled once the password is disabled the system will boot and you can enter setup freely the bios setup program allows you to specify two separate passwords supervisor password and a user password when disabled anyone may access all bios setup program function when enabled the supervisor password is required for entering the bios setup program and having full configuration fields the user password is required to access only basic items if you select system at password check in advance bios features menu you will be prompted for the password every time the system is rebooted or any time you try to enter setup menu if you select setup at password check in advance bios features menu you will be prompted only when you try to enter setup 49
- 11 save exit setup 50
- 12 exit without saving 50
- English 50
- Ga 8i915p dual graphic motherboard 50 50
- Type y will quit the setup utility and save the user setup value to rtc cmos type n will return to setup utility 50
- Type y will quit the setup utility without saving to rtc cmos type n will return to setup utility 50
- 1 install chipset drivers 51
- Chapter 3 install drivers 51
- English 51
- 2 software applications 52
- 3 driver cd information 52
- English 52
- 4 hardware information 53
- 5 contact us 53
- English 53
- English 54
- 1 unique software utilities 55
- C i a cpu intelligent accelerator 2 55
- C o m corporate online management 55
- Chapter 4 appendix 55
- Download center 55
- English 55
- M i b memory intelligent booster 2 55
- M i t motherboard intelligent tweaker 55
- S o s system overclock saver 55
- U plus d p s universal plus dual power system 55
- 1 1 easytune 5 introduction 56
- English 56
- User interface overview 56
- 1 2 xpress recovery introduction 57
- Boot from cd 57
- English 57
- How to use the xpress recovery 57
- What is xpress recovery 57
- English 58
- F9 for xpress recovery 58
- English 59
- 1 3 flash bios method introduction 60
- A what is dual bios technology 60
- B dual bios q flash programming utility 60
- B how to use dual bios and q flash utility 60
- Dual bios means that there are two system bios rom on the motherboard one is the main bios and the other is backup bios 60
- English 60
- Ga 8i915p dual graphic motherboard 60 60
- To enter flash utility 60
- Under the normal circumstances the system works on the main bios if the main bios is corrupted or damaged the backup bios can take over while the system is powered on this means that your pc will still be able to run stably as if nothing has happened in your bios 60
- Auto recovery enable default disable 61
- Bios recovery backup to main 61
- Bios recovery main to backup 61
- Boot from main bios default backup bios 61
- Copy main rom data to backup 61
- English 61
- Halt on error disable default enable 61
- Keep dmi data enable default disable 61
- Load default settings 61
- Save settings to cmos 61
- Wide range protection disable default enable 61
- Before you begin 62
- English 62
- Method 1 q flas 62
- Part one updating bios with q flas 62
- Utility 62
- Utility on dual bios motherboards 62
- Action bar 63
- Appendix 63 63
- Contains the names of eight tasks and two item showing information about the bios rom type blocking a task and pressing enter key on your keyboard to enable execution of the task 63
- Contains the names of four actions needed to operate the q flash dual bios utility pressing the buttons mentioned on your keyboards to perform these actions 63
- Contains the names of four tasks blocking a task and pressing enter key on your keyboard to enable execu tion of the task 63
- Dual bios utility bar 63
- Dual bios utility screen 63
- English 63
- Entering the q flas 63
- Exploring the q flas 63
- Q flas 63
- Step 2 press f8 button on your keyboard and then y button to enter the dual bios q flash utility 63
- Step1 to use q flash utility you must press del in the boot screen to enter bios menu 63
- Task menu for dual bios 63
- Task menu for dual bios utility 63
- Task menu for q flas 63
- Task menu for q flash utility 63
- The q flash dual bios utility screen consists of the following key components 63
- Utility 63
- Utility title 63
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios 64
- After pressing enter you ll then see the progress of reading the bios file from the floppy disk 64
- Bios file in the floppy disk 64
- Do not trun off power or 64
- English 64
- Ga 8i915p dual graphic motherboard 64 64
- If you want to save the current bios for backup purpose you can begin step 1 with save main bios to floppy item 64
- In this example we only download one bios file to the floppy disk so only one bios file 8knxpu fba is listed 64
- Move to the bios file you want to flash and press enter 64
- Please confirm again you have the correct bios file for your motherboard 64
- Press arrow buttons on your keyboard to move the light bar to load main bios from floppy item in the q flash menu and press enter button later you will see a box pop up showing the bios files you previously downloaded to the floppy disk 64
- Reset your system at this stage 64
- This section tells you how to update bios using the q flash utility as described in the before you begin section above you must prepare a floppy disk having the bios file for your motherboard and insert it to your computer if you have already put the floppy disk into your system and have entered the q flash utility please follow the steps below to flash bios 64
- Using the q flas 64
- Utility 64
- After system reboots you may find the bios version on your boot screen becomes the one you flashed 65
- Appendix 65 65
- English 65
- Please do not take out the floppy disk when it begins flashing bios 65
- Press any keys to return to the q flash menu when the bios updating procedure is completed 65
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash 65
- Press y button on your keyboard after you are sure to update bios then it will begin to update bios the progress of updating bios will be displayed 65
- The bios file becomes fab after 65
- To flash the backup bios too 65
- Updating 65
- You can repeat step 1 to 65
- English 66
- Ga 8i915p dual graphic motherboard 66 66
- Part two 66
- Press del to enter bios menu after system reboots when you are in bios menu move to load fail safe defaults item and press enter to load bios fail safe defaults normally the system redetects all devices after bios has been upgraded therefore we highly recommend reloading the bios defaults after bios has been upgraded 66
- Press y on your keyboard to load defaults 66
- Press y on your keyboard to save and exit 66
- Select save exit setup item to save the settings to cmos and exit the bios menu system will reboot after you exit the bios menu the procedure is completed 66
- This part guides users of single bios motherboards how to update bios using the q flas 66
- Updating bios with q flas 66
- Utility 66
- Utility on single bios motherboards 66
- Action bar 67
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios 67
- Appendix 67 67
- Bios file in the floppy 67
- Contains the names of four actions needed to operate the q flash utility pressing the buttons mentioned on your keyboards to perform these actions 67
- Contains the names of three tasks blocking a task and pressing enter key on your keyboard to enable execution of the task 67
- Do not trun off power or 67
- English 67
- Exploring the q flas 67
- If you want to save the current bios for backup purpose you can begin step 1 with save bios to floppy item 67
- Move to the bios file you want to flash and press enter in this example we only download one bios file to the floppy disk so only one bios file 8ge800 f4 is listed 67
- Please confirm again you have the correct bios file for your motherboard 67
- Please do not take out the floppy disk when it begins flashing bios 67
- Press arrow buttons on your keyboard to move the light bar to update bios from floppy item in the q flash menu and press enter button later you will see a box pop up showing the bios files you previously downloaded to the floppy disk 67
- Q flas 67
- Reset your system at this stage 67
- Task menu for q flas 67
- Task menu for q flash utility 67
- The q flashbios utility screen consists of the following key components 67
- This section tells you how to update bios using the q flash utility as described in the before you begin section above you must prepare a floppy disk having the bios file for your motherboard and insert it to your computer if you have already put the floppy disk into your system and have entered the q flash utility please follow the steps below to flash bios 67
- Using the q flas 67
- Utility 67
- Utility bar 67
- Utility screen 67
- After system reboots you may find the bios version on your boot screen becomes the one you flashed 68
- At this stage 68
- Congratulation you have updated bios successfully 68
- Do not trun off power or reset your system 68
- English 68
- Ga 8i915p dual graphic motherboard 68 68
- Press any keys to return to the q flash menu when the bios updating procedure is completed 68
- Press del to enter bios menu after system reboots and load bios fail safe defaults see how to load bios fail safe defaults please kindly refer to step 6 to 7 in part one 68
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash 68
- Press y button on your keyboard after you are sure to update bios then it will begin to update bios the progress of updating bios will be shown at the same time 68
- The bios file becomes f4 after updating 68
- English 69
- Method 2 bio 69
- Methods and steps 69
- Utility 69
- English 70
- 1 4 serial ata bios setting utility introduction 71
- English 71
- Raid levels 71
- Configuring the intel raid bios 72
- English 72
- Ga 8i915p dual graphic motherboard 72 72
- Please follow the steps below to construct a complete raid array 1 have ready your hard drives for raid construction note to achieve best performance it is recommended that the hard drives used are of similar make and storage capacity 2 please attach the hard drive connectors to their appropriate location on the motherboard ie ide scsi or sata 3 enter the motherboard bios and locate raid setup please refer to the section on integrated peripherals 4 enter raid setup in the bios and select the raid type for instance enter ctrl i to select intel raid ctrl s to select silicon image 5 complete driver installation 6 complete raid utility installation more information on steps 4 and 5 is provided 72
- Press ctrl i the intel raid utility create raid volume window appears as figure below 72
- The intel raid bios setup lets you choose the raid array type and which hard drives you want to make part of the array entering the raid bios setup 1 after rebooting your computer wait until you see the raid software prompting you to press ctrl i the raid prompt appears as part of the system post and boot process prior to loading the os you have a few seconds to press ctrl i before the window disappears 72
- After entering the create volume menu you can set disk name with 1 16 letters letters cannot be special characters under name item after setting disk name press enter to select raid level 73
- Appendix 73 73
- Create raid volume 73
- English 73
- Press enter under create raid volume to set up raid 73
- There are two raid levels raid0 stripe and raid1 mirror after selecting the raid level press enter to select strip size 73
- English 74
- Ga 8i915p dual graphic motherboard 74 74
- Press enter to enter create volume after setting disk capacity 74
- The kb is a unit of strip size you can set disk block size with this item the disk block size can be set from 4kb to 128kb after you set disk block size press enter to set disk capacity 74
- An alert bar will be displayed warning you that all data on selected disks will be lost please press y to complete the set up of raid 75
- Appendix 75 75
- English 75
- Press enter under the create volume item 75
- After the completion you will see the detailed information about the raid such as raid level disk block size disk name and disk capacity etc 76
- Delete raid volume 76
- English 76
- Ga 8i915p dual graphic motherboard 76 76
- If you want to delete a raid volume please select the delete raid volume option press enter key and follow the instructions on the screen 76
- English 77
- Installing the raid drivers 77
- 1 5 2 4 5 7 channel audio function introduction 78
- English 78
- Channel audio setup 79
- English 79
- Channel audio setup 80
- English 80
- Channel audio setup 81
- English 81
- Channel audio setup 82
- English 82
- Device setting 83
- Digital i o status 83
- Effect 83
- English 83
- 2 troubleshooting 84
- English 84
- English 85
- English 86
- Appendix 87 87
- Contact us 87
- English 87
- English 88
- Ga 8i915p dual graphic motherboard 88 88
Похожие устройства
- Gigabyte GA-8I915G Pro (rev. 2.x) ATA RAID Controller
- Gigabyte GA-8I915G Pro (rev. 2.x) Configuring IDE RAID Hard Drive
- Roland V-Synth Инструкция по эксплуатации
- Roland V-Synth Руководство пользователя
- Roland KR-7 Руководство пользователя
- Roland KR-7 Инструкция по эксплуатации
- Roland KR-5 Инструкция по эксплуатации
- Roland KR-5 Руководство пользователя
- Roland FP-5 Руководство пользователя
- Roland FP-5 Инструкция по эксплуатации
- Liebherr CTN(es) 3153 Руководство пользователя
- Akai LTA-37C902 (N) Руководство пользователя
- Akai LTA-32C902 (N) Руководство пользователя
- Hyundai H-MP318 Руководство пользователя
- Samsung SGH-S500 Руководство пользователя
- Samsung SGH-S300 Руководство пользователя
- HTC TyTN II Руководство пользователя
- Samsung SGH-S200 Руководство пользователя
- Samsung SGH-S100 Руководство пользователя
- Samsung SGH-R210S Руководство пользователя
