GigaRAID (IT8212) ATA RAID Controller USER’S MANUAL

The hard drives which are required for the installation

The hard drives, which are connected on the GigaRAID (IT8212) ATA RAID Controller,

can support Ultra ATA/ 133, Ultra ATA/ 100, Ultra ATA/ 66, Ultra ATA/33, EIDE or Fast

ATA-2 drives. Nevertheless, for the best performance, it is suggested that you had

better use the hard drives of the same type and capacity to establish your own RAID

system. After getting ready for the hard drives, you can follow the procedures below

to install the system.

1. Exactly set up every hard drive’s master and slave setting to assure that the

hard drives can surely action and unnecessarily incorrect action of data access

won’t occur.

2. Exactly insert the hard drive’s cables into the connectors on the hard drive and

check if it’s really firmly inserted.

3. Insert every power cable connector into the corresponding hard drive and

check if it’s firmly inserted in a correct direction.

Warning: Because this system can support the hard drives of

Ultra ATA/133, it is suggested that you can use the 80-wire,

40-pin cable to connect the GigaRAID (IT8212) ATA RAID

Controller and hard drives in order to assure the system’s ability

and efficiency. If the cable is damaged after a period of time, it is also

suggested to buy the cable of the same specification.
