Daikin RZQ200B8W1B [12/52] Options
Превью страниц
Страница 12 /
52
![Daikin RZQ200B8W1B [12/52] Options](/views2/1794899/page12/bgc.png)
4
• Split Sky Air • Outdoor Units
11
• Outdoor Units • R-410A • RZQ-B9V3B_RZQ-B8W1B
4 Options
Available option for RZQ71-125B8V3 and RZQ100-140BW1
Name of option
Kit name
RZQ71B8V3 RZQ100B8V3 RZQ125B8V3
RZQ100BW1 RZQ125BW1 RZQ140BW1
Central drain plug KKPJ5F180
Refrigerant branch piping Twin KHRQ22M20TA
Triple - KHRQ127H
Double twin - - KHRQ22M20TA (3x)
Demand adapter kit KRP58M51
3TW26739-1A
Available options for RZQ200,250BW
Name of option
Kit name
RZQ200BW RZQ250BW
Central drain pan kit KWC26B280
Refrigerant branch piping Twin KHRQ22M20TA
Triple KHRQ250H7
Double twin KHRQ22M20TA (3x)
4TW26569-3A
