Comet MTP AXR 9/140 TSI [2/4] 0019 005

Comet MTP AXR 11/140 с эл. двигателем 3,7 Квт 380 В [2/4] 0019 005
2
REVISIONE Nr.
REVISION Nr.
01
DATA EMISSIONE
PRINTING DATE
Marzo / March 2017
Kit Ricambi
Spare Parts Kit
MTP AXR
Motopompe - Motorpumps
2800 RPM
N° Cod. Descrizione Description Note
Q.ty
Model N° Cod. Descrizione Description Note
Q.ty
Model
1 2803 0435
Kit Raccordo Asp.
Deterg.
Chem. Coupling Kit
1
2 1802 0180
Molla Detergente Detergent Spring
1
3 3003 0024
Sfera Ball 7/32"
1
4 2803 0424
Raccordo Asp. Deterg. Chem. Coupling
1
5 3202 0018
Tappo Cap G1/8"
1
6 3609 0014
Vite Screw M8x55
4
7 3218 0327
Testata Pompa Manifold
1
3218 0329
Testata Pompa Manifold
1
Solo / Only
TS
8 1220 0058
Gruppo Valv. Asp./
Mand.
Suct./Del. Valve
Ass.y kit
6
1220 0045
Gruppo Valv. Asp./
Mand.
Suct./Del. Valve
Ass.y kit
6
Solo / Only
8/120TS - 9/140TS
9 1210 0049
Guarnizione OR O-Ring Ø1,78x12,42
6
10 3009 0170
Sede Valvola Regol. Valve Seat
6
11 3604 0028
Valvola Aspir./Mand. Suct./Del. Valve
6
12 1802 0227
Molla Valv. Asp./Mand. Suct./Del. Valve Spring
6
1802 0192
Molla Valv. Asp./Mand. Suct./Del. Valve Spring
6
Solo / Only
8/120TS - 9/140TS
13 1205 0037
Gabbia Valv. Asp./
Mand.
Suct./Del. Valve Cage
6
1205 0033
Gabbia Valv. Asp./
Mand.
Suct./Del. Valve Cage
6
Solo / Only
8/120TS - 9/140TS
14 0601 0273
Distanziale Spacer
2
15 1210 0151
Guarnizione OR O-Ring Ø1,78x17,17
6
16 3202 0236
Tappo Plug
6
17 2409 0089
Pistone Piston Ø14
3
17 2409 0087
Pistone Piston Ø14 Inox
3
Solo / Only
8/120TS - 8/140TS
18 1802 0153
Molla Spring
3
19 0009 0221
Anello Ring
3
20 0009 0220
Anello Ring Ø14
3
21 1210 0429
Guarnizione OR O-Ring Ø3x92
1
22 0001 0432
Albero Eccentrico Eccentric Shaft 7°
1
8/120 - 8/120TS
0001 0417
Albero Eccentrico Eccentric Shaft 8°
1
9/140 - 9/140TS
0001 0480
Albero Eccentrico Eccentric Shaft 9°30’
1
11/120 - 11/120TS
0001 0481
Albero Eccentrico Eccentric Shaft 10°
1
11/140 - 11/140TS
11/170 - 11/170TS
23 0436 0017
Cuscinetto Assiale Axial Bearing Ø45x65x14
1
24 2816 0088
Ralla Cuscinetto Thrust Bearing
1
25 3609 0005
Vite Screw M8x20
1
26 1817 0064
Manopola Knob
1
27 1215 0584
Kit Valvola Regolazione Regulation Valve Ass.y 140 bar
1
8/120 - 8/120TS
11/120 - 11/120TS
1215 0585
Kit Valvola Regolazione Regulation Valve Ass.y 180 bar
1
9/140 - 9/140TS
11/140 - 11/140TS
11/170 - 11/170TS
28 3609 0028
Vite Screw M8x22
4
29 3201 0027
Spia Livello Olio Oil Indicator G1/2”
1
30 1210 0048
Guarnizione OR O-Ring Ø2,62x20,24
1
31 3200 0086
Tappo Plug
1
8/120
3200 0071
Tappo Plug
1
9/140 - 11/120
11/140
32 0403 0135
Carter Pompa Pump Crankcase
1
0403 0145
Carter Pompa Pump Crankcase
1
Solo / Only
11/140
33 3200 0096
Tappo Cap G1/4"
1
Solo / Only
11/140 - 11/170
34 1209 0117
Guarnizione Seal Ø13x20x2
1
Solo / Only
11/140 - 11/170
35 0019 0058
Anello Tenuta Olio Oil Seal Ø14x22x5/7
3
0019 0123
Anello Tenuta Olio Oil Seal Ø14x22x5/7
3
Solo / Only
11/140 - 11/170
36 0601 0308
Distanziale Paraolio Oil Seal Spacer
3
37 1241 0057
Guarnizione Tenuta Packing Ø14x22x4
3
38 1210 0356
Guarnizione OR O-Ring Ø1,78x25,12
3
39 0009 0219
Anello Porta Guarniz. Packing Retainer
3
40 0009 0369
Anello Ring
3
41 1241 0059
Guarnizione Tenuta Packing
3
42 2409 0091
Kit Pistone NON Ritorno Check Valve Kit
1
43 1210 0460
Guarnizione OR O-Ring Ø2,4x4,3
1
44 2409 0086
Pistone NON Ritorno Check Valve
1
45 1802 0197
Molla Spring
1
46 3410 0311
Kit Eiettore Injector Body Kit M22x1,5
1
47 1210 0040
Guarnizione OR O-Ring Ø1,78x15,6
1
48 1210 0049
Guarnizione OR O-Ring Ø1,78x12,42
1
49 3200 0007
Tappo Cap G3/8”
1
3200 0084
Tappo Cap G3/8”
1
Solo / Only
11/140TS
11/170TS
50 3202 0018
Tappo Cap G1/8”
1
51 3200 0017
Tappo Plug G1/8x8
1
52 2000 0127
Nipplo Nipple
1
Solo / Only
TS
53 1002 0132
Filtro Acqua Water Filter
1
54 2803 0325
Raccordo Aspirazine Quick Coupler
1
55 0111 0010
Kit Asta Total Stop Total Stop Rod Kit
1
Solo / Only
TS
0111 0006
Kit Asta Total Stop Total Stop Rod Kit
1
Solo / Only
11/140TS
11/170TS
56 2811 0127
Rondella Rame Copper Washer Ø14x18x1,5
1
Solo / Only
TS
57 3605 0117
Vite Speciale Special Screw
1
58 0009 0229
Anello Ring
1
59 2416 0112
Protezione Interruttore Switch Protection
1
60 3001 0538
Scatola Total Stop Total Stop Box
1
61 1201 0137
Guarnizione Gasket PG11
1
62 1200 0056
Galletto Ring Nut PG11
1
63 0456 0326
Cavo Total Stop Total Stop Cable MNF
1
8/120TS
0456 0264
Cavo Total Stop Total Stop Cable MNF
1
9/140TS
11/120TS
0456 0270
Cavo Total Stop Total Stop Cable TRF
1
11/140TS
11/170TS
64 3625 0048
Vite Screw 3x10
3
Solo / Only
TS
65 0402 0200
Coperchio Cover
1
Solo / Only
TS
66 1201 0136
Guarnizione OR O-Ring Ø2x118,5
1
Solo / Only
TS
67 1825 0018
Interruttore Total Stop Total Stop Switch 16A
1
8/120TS - 9/140TS
11/120TS
1825 0010
Interruttore Total Stop Total Stop Switch 10A
1
Solo / Only
11/140TS
11/170TS
68 1202 0066
Gancio ad “U” “H” Hook
1
Solo / Only
TS
69 0608 0030
Kit Easy Start Easy Start Kit
1
8/120TS - 9/140TS
11/120TS
69 3200 0084
Tappo Easy Start Easy Start Cap
1
11/140TS
11/170TS
70 1816 0125
Manometro Gauge Ø40 G1/8”
0-160bar
1
8/120TS
1816 0104
Manometro Gauge Ø40 G1/8”
0-300bar
1
11/140TS
11/170TS
1816 0137
Manometro Gauge Ø40 G1/8”
0-300bar
1
9/140TS
1816 0100
Manometro Gauge Ø40 G1/8”
0-160bar
1
11/120TS
100 5019 0078
Kit Guarnizioni Acqua Water Seal Kit
1
101 5025 0014
Kit Valvola Valve Kit
1
102 5019 0079
Kit Guarnizioni Olio Oil Seal Kit
1
103 3103 0023
Kit Total Stop Completo Complete Total Stop
Kit
MNF
1
8/120TS - 9/140TS
11/120TS
3103 0038
Kit Total Stop Completo Complete Total Stop
Kit
TRF
1
Solo / Only
11/140TS
11/170TS
