ENGLISH

To store your favorite programme types

Press and hold the button for more than 2

seconds to call up the general settings mode

(see page 27).

Select “PTY SRCH(Search)” if not shown on

the display.

Select one of twenty-nine PTY codes. (See

the table on page 17.)

Selected code name appears on the display.

• If the code already stored in memory is selected, it will

flash on the display.

Press and hold the number button for more than 2 seconds to

store the PTY code selected into the preset number you want.

The PTY code starts flashing.

Finish setting.

SEL

1, 5 2

SEL

EN13-17.KD-SX855R[E]/1 99.3.29, 11:38 AM14
