23
E.g.:TW10522(105x0.378=39.7l/min),LW2015(20:10=2USgpm).
Bymeansofthelasttwogures,themaximumpressurecanbedeterminedaccordingtothefollowingtable:
Max pressure in bar = last two gures x 6.9
Max pressure in psi = last two gures x 100
E.g.:TW10522(22x6.9=151.8bar),LW2015(15x100=1500psi).
NOTE:
inthecaseofFW2,the“2”mustbeexcludedfromwhatisbeforewhichidentiesthesecondseries
ofFWpumps.
IDENTIFICATION OF COMPONENTS
RefertoFiguresfrom1to3atthebeginningofthemanual.
1. Suction tting
2. Pump head
3. Suction valve cap
4. Pressure gauge tting
5. Delivery tting
6. Delivery valve cap
7. Identication plate
8. Oil cap with vent
9. Pump crankcase
10. Oil level indicator
11. Motor ange support
12. Pump shaft
13. Oil drain cap
14. Detergent suction tting
15. Pressure adjustment knob
16. Detergent adjustment knob
17. Oil cap without vent
18. Pump foot
19. Safety valve connector
20. Thermal valve connector
PUMP IDENTIFICATION PLATE
WARNING
•Shouldtheidenticationplatedeteriorateduringuse,contacttheManufactureroraSkilled Technician to
haveitrestored.
eidenticationplate(7)showstheserialnumberandthepumpmodelbymeansofaspeciccodewhich
permitsidentifyingthemaintechnicalspecications(see
“SPECIFICATIONS AND TECHNICAL DATA”
paragraph).It
islocatedonthepumpcrankcase.
SAFETY DEVICES
WARNING
•emachineinwhichthepumpisintegratedmustalwaysfeatureapressureunloader/regulationvalve.
•Ifthemachineinwhichthepumpisintegratedalsofeaturesasafetyvalve,i.e.,amax.pressurevalve,suitably
calibrated,whichdischargesexcesspressureincaseofafaultinthehigh-pressurecircuit,intheeventofthe
safetyvalvetrippingfrequently,immediatelystopusingthemachineinwhichthepumpisintegratedandhave
itcheckedbyaSkilled Technician.
Pressure unloader/regulation valve.
StandardonpumpsmarkedwiththeletterKprecededbyadashandontheAXandBXseriespumps.Available
asanoptionalaccessoryfortheothermodels.
isvalveissuitablysetbytheManufacturer,allowsregulatingtheoperatingpressureandpermitsthepumped
uidtoowbacktowardsthebypassduct,thuspreventingtheaccumulationofdangerouspressureswhen
thedeliverylineisclosedorwhenattemptsaremadetosetpressurevaluesabovethemaximumonesallowed.
EN
