![Comet KM Classic 8.15 15/200 FW2 [16/16] 0455 001](/views2/1796567/page16/bg10.png)
16
REVISIONE NR.
REVISION NR.
02
DATA EMISSIONE
PRINTING DATE
Aprile / April 2017
1
2
3
5 6
7
8
10
9
4
1 0455 0013
Spillo Pulizia Ugello Nozzle Cleaning Pin
1
2 3400 0705
Ugello Acqua Water Nozzle Ø1,35
(Blister COMET)
1
3.11 MNF
8.15 TRF
3400 0705
Ugello Acqua Water Nozzle Ø1,35
(Blister COMET)
1
5.15 TRF
Con Cisterna
With Water
Tank
3400 0703
Ugello Acqua Water Nozzle Ø1,27
(Blister COMET)
1
5.13 TRF LW
5.13 TRF ZW
3400 0707
Ugello Acqua Water Nozzle Ø1,4
(Blister COMET)
1
5.15 TRF
3400 0703
Ugello Acqua Water Nozzle Ø1,27
(Blister COMET)
1
3.11 MNF
8.15 TRF
Con Cisterna
With Water
Tank
3400 0702
Ugello Acqua Water Nozzle Ø1,19
(Blister COMET)
1
5.13 TRF
Con Cisterna
With Water
Tank
3 3301 0787
Lancia Angolata Bent Lance
(Blister COMET)
1
3301 1353
Lancia Angolata Bent Lance
(Blister COMET)
1
Solo / Only
Con Cisterna
With Water
Tank
4 2410 0182
Pistola Spray Gun
(Blister COMET)
1
5 1210 0469
Guarnizione OR O-Ring Ø1,5x4
1
6 1210 0014
Guarnizione OR O-Ring Ø1,78x4,48
1
7 2800 0101
Raccordo Coupling
1
8 3208 0829
Tubo Detergente Detergent Hose
Ø7x10 L=1000
1
9 1002 0109
Filtro Detergente Detergent Filter
1
10 3208 1050
Tub o A .P. H.P. Hose R1 1/4"
L=10 mt
(Blister COMET)
1
3.11 MNF
3301 0987
Tub o A .P. H.P. Hose R1 5/16"
L=10 mt
(Blister COMET)
1
5.13 TRF
5.15 TRF
3301 0776
Tub o A .P. H.P. Hose R2 5/16"
L=10 mt
(Blister COMET)
1
8.15 TRF
N° Cod. Descrizione Description Note
Q.ty
Model N° Cod. Descrizione Description Note
Q.ty
Model
KM - Classic
Dotazione Standard
Standard Equipment
