11 Technical data
Installation manual
43
ETVH16SU18+23EA6V
Daikin Altherma 3 H HT F
4P644729-1 – 2021.02
11.3 Technical specifications: Domestic
hot water tank
11.3.1 Test results in accordance with EN12897
(2016)
INFORMATION
This unit has been tested and approved according to
BSEN12897:2016
Description Hot water capacity Reheat time
ETVH16SU18EA6V 163l 18min 07sec
ETVH16SU23EA6V 200l 23min 05sec
11.3.2 Warning label
WARNING TO USER
■ Do not remove or adjust any component part of this installation.
Contact the installer.
■ Should the system develop a fault, switch the system off and
contact the installer.
WARNING TO INSTALLER
■ This installation is subject to building regulation approval,
notify Local Authority of intention to install.
■ Use only manufacturer's recommended spare parts.
Contact your local Daikin dealer.
■ Installed by
name
address
tel. No.
completion date
TECHNICAL SPECIFICATIONS EN12897: 2016
■ Maximum water supply pressure to pressure reducing valve: 16 bar
■ Operating pressure/set pressure of pressure reducing valve: 3.5 bar
■ Maximum primary working pressure (heating): 2.5 bar
■ Maximum flow temperature: 65
o
C
■ Expansion vessel pre-charge pressure: 3.5 bar
■ Expansion valve setting: 8 bar
■ Temperature and pressure relief valve
replacement part No.: 302810P
■ Operating pressure of temperature and pressure
relief valve: 10 bar
■ Operating temperature of temperature and pressure
relief valve: 95
o
C
■ Operating temperature of thermal cut-out (2 pieces): 89
o
C
■ Primary heating power input:
ETVH16SU18EA6V 30.05 kW
ETVH16SU23EA6V 30.12 kW
■ Primary flow rate to reach primary heating power input: 15 l/min
■ Standing heat loss:
ETVH16SU18EA6V 1.35
kWh/
24
h
ETVH16SU23EA6V 1.76
kWh/
24
h
■ Model storage capacity mass of unit when full
ETVH16SU18EA6V 180 l 289 kg
ETVH16SU23EA6V 220 l 338 kg
■ Maximum design pressure: 10 bar
■ Rated volume heat exchanger: 9.1 l
4P647876-1A
