Popcorn Hour A-110 [12/112] Minimum system requirements
![Popcorn Hour A-110 [12/112] Minimum system requirements](/views2/1798106/page12/bgc.png)
12
// Popcorn Hour A-110
2.4 Minimum System Requirements
High-Denition (HD) or standard television (TV) with HDMI, S-Video, Component Video, • or
Composite Video input
TV, Ster• eo, or HD Audio receiver with Optical Digital, Coaxial Digital, or Composite Audio input
Wir• ed or wireless network (wired 100Mbps or better network is recommended for networked
video streaming)
Connection to the Internet • (for use with Web Services)
Listed below are the minimum requirements for installation of the myiHome Media Server
software application on your PC.
Pentium 233(MHz) or higher processor • (Pentium III or higher recommended)
Microsoft Windows® 2000, XP, Vista (32 or 64-bit); Mac OS X or Linux operating systems•
512MB of RAM•
100MB of available hard disk drive (HDD) space•
