to display if the low pressure alarm prevention function in winter mode is active for circuits 1 and 2.

2.3 Switching ON/OFF he unit from keyboard

select "On/OFF unit" menu "Enter" "Enter"to switch ON/OFF the unit.

If time slots are active, the unit will start running only if it is programmed to be ON in that time slot.

IftheunitON/OFFswitchingfromasupervisorsystemisenabled,theserialconsentisnecessaryforthee󰀨ective

unit starting-up.

IftheunitON/OFFswitchingfromdigitalinputisenabled,theON/OFFdigitalinputmustbeclosedforthee󰀨ective

unit starting-up.

If even only one of the previous starting-up systems does not give its consent, the unit will not start running.

2.4 Temperatureandairowsetpointadjust

select "Setpoint" menu "Enter" .

FromS0mask,theindoortemperaturesetpointinsummermode(cooling)canbeadjusted:press"enter"key ,

adjustthesetpointvaluewitharrowkeysandpress againtoconrmthenewvalue.

Iftimeslotsareactive,thesetpointcannotbemodiedfromthismask,butonlyfromthespecicmaskoftheClock

menu.

fromS1mask,theindoortemperaturesetpointinwintermode(heating)canbeadjusted:pressthekey ,

adjustthesetpointvaluewitharrowkeysandpress againtoconrmthenewvalue.

Iftimeslotsareactive,thesetpointcannotbemodiedfromthismask,butonlyfromthespecicmaskoftheClock

menu.

fromS5mask,thedeliveryairowcanbeadjusted:pressthekey ,adjustthesetpointvaluewitharrow

keys and press againtoconrmthenewvalue.

TherealairowcanbereadfromnextmaskS6.
