ENGLISH
ENGLISH
24
Installation
Mains Lead
Remove the mains lead from the storage compartment in the
bottom section.
Mixing Vessel
1. Check any preassembled parts! (Fig. A + B)
The safety disc (4), sealing ring (5), blade block (6) and
screw top (7) must be assembled in the correct order.
CAUTION:
• Do not forget to insert the sealing ring as otherwise
the carafe will leak.
• Always place the sealing ring on the blade block.
• The screw top must be straight when screwed into
place.
• The three guide mechanisms of the safety disc must
lie in the recesses of the screw top.
2. Place the carafe on the motor housing (8) (Fig. C). You can
select whether the handle of the carafe should point to the
left or right.
NOTE:
When the carafe is placed in position the assembled safe-
ty disc presses on the safety switch of the motor housing.
If incorrectly installed the mixer cannot be operated.
Instructions for Use
• Please clean the mixer vessel, the lid and seal before initial
use in warm soapy water.
• Please cut the items that are to be mixed into small pieces
beforehand.
• Ingredients: Do not put any hot items into the mixing ves-
sel.
• Seal: The seal can also be used as a measuring jug (full to
the brim = 50 ml).
• Short-term operation: The device is suitable for short-term
operation of not more than 1 minute. After this time it should
be switched off.
• Pulse operation: Pulse mode is turned on by turning the
switch to the “P” position and releasing it again. The device
should not be used in this mode for more than 1 minute.
Allow it to cool down for 2 minutes before using it again!
• Chopping up Ice Cubes: The blade in the mixing vessel
is also suitable for chopping up ice cubes. Please only fi ll
the carafe up to 1/3 full with ice cubes. Only pulse mode “P”
should be used for chopping up ice cubes.
Operation
Electrical connection
Check whether the electrical voltage that you intend to use is
the same as that of the machine. Details are to be found on the
label on the base.
Preparation
• Ensure that the function switch (9) is in the “0” position.
• Place the mixing vessel in position.
• Now put the ingredients that are to be mixed into the mixing
vessel (max. 1.5 litres).
• Press the lid (2) tightly onto the carafe (Fig. D). It must
tightly seal the mixer vessel.
• Close the lid with the seal (1) (Fig. E). Note the recesses on
the inside of the lid. Turn the seal tight in a clockwise direc-
tion.
• Connect the mains lead to a properly installed 230 V, 50 Hz
safety power socket. The switch ring (10) lights up.
• Please hold the carafe fi rmly during mixing.
Mixing
• For constant mixing (continuous mode):
If the device is operated on levels 1 and 2 the switch locks in
place in the respective position.
Level 1 = low rpm
Level 2 = high rpm
Shift the selector to “0” to switch off the appliance.
• For pulse mode (mixing at brief intervals):
Move the switch to the “0” position. The switch snaps into
place. The appliance is off now. Turn the switch now to
position “P”. The switch must be kept in this position for
the desired interval. When the switch is released, it returns
automatically to “0” position.
Adding further ingredients to be mixed
Please switch off the machine before doing so. Spices or other
ingredients that are to be mixed can be inserted through the hole
in the seal.
Stopping Operation
• Turn the switch to the “0” position.
• Remove the mains plug from the socket
. The illumination
goes off.
• Remove the mixing vessel.
• Take off the lid before pouring.
IMPORTANT NOTE:
Citrus juices and food containing acids should never be
stored in metal vessels.
• The mains lead can be stored in the bottom section.
Cleaning
Preliminary Cleaning
• Half fi ll the mixing vessel with water and turn the switch to
“P” for approximately 10 seconds. Then pour out the liquid.
WARNING:
• Always remove the plug before cleaning!
• Under no circumstances should you immerse the device
in water for cleaning purposes. Otherwise this might result
in an electric shock or fi re.
05-UM 1354 CB.indd 2405-UM 1354 CB.indd 24 04.06.2009 16:46:03 Uhr04.06.2009 16:46:03 Uhr
