Daikin ALB03LBSNADBT00 [7/8] Accessory list
![Daikin ALB07LBSNADBT00 [7/8] Accessory list](/views2/1801504/page7/bg7.png)
7
Accessory list
Control platform Accessory location
Accessories Pro Smart Fresh air Exhaust air Return air Supply air
Filter iso Coarse (G4), ePM10 (M5), ePM1 50% (F7) and ePM1 80% (F9)
• • • •
Rectangular-circular duct transition
• • • • • •
Silencer
• •
CO
2
sensor
• • •
Humidity sensor
• •
Pre Heating Coil (electrical or water)
•
only electrical
•
Heating and/or cooling water Coil
• •
Constant Air Volume System (CAV) to comply with ventilation needs
•
Variable Air Volume System (VAV) for energy saving based on local occupancy
•
Constant speed
• •
Rails (for limited false ceiling space)
• •
Technical details
Exhaust Air
Fresh Air
Return Air
Supply Air
0 500 1000 1500 2000 2500 3000 3500
D-AHU Modular L (Pro & Smart) 02 03 04 05 06 07
Airow m
3
/h 300 600 1200 1500 2500* 3000
Heat exchanger thermal eciency
1.
% 90 90 90 90 91* 90
External static pressure Nom. Pa 100 100 100 100 100 100
Current Nom. A 0,52 1,26 2,17 2,74 5,04* 6,09
Power input Nom. kW 0,12 0,29 0,50 0,63 1,16* 1,40
SFPv
2.
kW/m
3
/s 1,25 1,52 1,3 1,35 1,46* 1,5
ERP compliant ErP 2018 Compliant
Electrical supply
Phase ph 1 1 1 1 1 1
Frequency Hz 50/60 50/60 50/60 50/60 50/60 50/60
Voltage V 220/240 Vac 220/240 Vac 220/240 Vac 220/240 Vac 220/240 Vac 220/240 Vac
Main unit dimensions
Width mm 920 1100 1600 1600 2000 2000
Height mm 280 350 415 415 500 500
Length mm 1660 1800 2000 2000 2000 2000
Rectangular duct ange
Width mm 250 400 500 500 700 700
Height mm 150 200 300 300 400 400
Unit Sound Power Level (Lwa) dB 50 57 57 53 61* 58
Unit Sound Pressure Level
3.
dBA 33 39 39 35 43* 40
Weight unit kg 125 180 270 280 355 360
. Winter design condition: Outdoor: -°C, % Indoor: °C, %
. SFPv is a parameter that quanties the fan eciency ( the lower it is the better will be). This reduces if airow decreases.
. EN . Surrounding, Directivity (Q) = , @ ,m distance
. Electrical current is based on V
*Nominal air ow for Smart version: m
/h
*Smart version thermal eciency, current, power input and sound values may dier from the Pro version
