6
Association and Certication
Since 2010 Daikin is Eurovent certied, actively
working on the development of the certication
schemes together with EU legislation.
Modular L Pro & Smart
AHU N°: 14.05.003
Range: D-AHU
Air ow range
Modular L is available in 6 sizes covering a wide range of applications such as hotels, oces, schools and light commercial buildings.
The product has been designed and built in order to
achieve the best hygienic performance.
The unit has been tested and certied according to
the Hygienic Standard VDI 6022
Modular L is EPBD certied.
Since 2015 Daikin is proud member of
RLT association, participating to the RLT
certication scheme.
Size 7
Size 6
Size 5
Size 4
Size 3
Size 2
0 500 1000 1500 2000 2500 3000
3500
300
600
1200
1500
2300 2500
3000
Nominal airow (m
3
/h)
Airow rate (m
3
/h)
Modular L Pro & Smart together Only Modular L Pro Only Modular L Smart
Max airow calculated @100 Pa of ESPFrom 150 up to 3400 m
3
/h
