General-Fujitsu ASH9FSBCW [15/16] Part no

Name and Shape

Part No.

ASH9FSBCW ASH12FSBCW

0700076046 0700076046

9308117007 9308117007

0600185534 0600185534

9312133062 9312133062

9304358008 9304358008

Remote control

unit

Battery (penlight)

Cloth tape

Tapping screw

(4 x 25)

Wall hook bracket

STANDARD ACCESSORIES
