106
Specifications
Model : ARG18FUAL
ARG18UUAL
Slim size (217mm) allows installation even where the space
behind the ceiling is narrow.
217
Compact design
Ultra-slim duct air conditioner for easy installation
Wired R.C.
Universal Type
LOW STATIC PRESSURE DUCT
CONSTANT SPEED
ARG18ALCH
AOGA18ADTH
Capacity
EER
COP
Running Current
Moisture Removal
Airflow Rate (High)
Net Dimension H
x
W
x
D
Net Weight
Piping Connections (Small / Large)
Max Height Difference
Operation Range
Cooling
Heating
Drain Pipe Diameter (I.D./O.D.)
Max Pipe Length (Pre-Charge)
Refrigerant
Heating
Cooling/HeatingInput Power
Power Source 230/1/50
5.40
18,400
—
—
2.03 / —
2.66
—
9.00 / —
1.6
1,000
217x953x595
25.0 (55)
650x830x320
47.0 (103)
6.35/15.88
21.5/26.0
20(7.5)
8
0 to 43
—
R410A
230/1/50
5.40
18,400
6.00
20,500
1.92 / 1.87
2.81
3.21
8.88 / 8.70
1.6
1,000
217x953x595
25.0 (55)
650x830x320
52.0 (114)
6.35/15.88
21.5/26.0
20(7.5)
8
0 to 43
-6 to 24
R410A
Cooling
Cooling
Indoor
Heating
Cooling/Heating
Indoor
Outdoor
°CDB
mm
m
kg(lbs)
mm
kW
kg(lbs)
A
W/W
m
3
/h
I/h
mm
V/ Ø/Hz
kW
BTU/h
kW
BTU/h
Model No.
Indoor unit
Outdoor unit
ARG18FUAL
AOG18FNDN
ARG18UUAL
AOG18UNDNL
107
SPLIT / CONSTANT SPEED
Flexible installation
Two-direction drain piping
Air-intake
Filter (Accessory)
Back side
Bottom side
Filter
(3pcs.)
Air intake direction can be selected to match the installation site.
Floor concealed
Ceiling concealed
Two-direction drain piping
Duct indoor unit
Optional parts
Simple Remote Controller: UTB-GPB
Remote Sensor Unit: UTD-RS100 / UTY-XSZX
IR Receiver Unit: UTY-LRJG1
Drain Pump Unit: UTZ-PX1BBA
IR Receiver unit
Wireless R.C.
Max. length : 10m
Optional function for comfort
Dimensions Models: (Unit : mm)ARG18FUAL / ARG18UUAL
Refrigerant piping flare connection (Gas)
Refrigerant piping flare connection (Liquid)
Drain piping connection
2
1
3
*Service accessibility must be allowed for when installing the product.
Please consult the installation manual for the necessary service access size.
2
1
3
Control box
Brackets
Brackets
Airflow outlet
Control box
886
(Bolt pitch)
(Bolt pitch)
850
390166
595
20
24
47
85
587
194
150
75
65
344
953
600
94
10
217
150
886
167
217
(Bolt pitch)
