When you order parts, please make a photocopy of this page

and fill the number of the parts in the "Order" column.

INDOOR UNIT

PARTS LIST

Ref.

No.

Description

AWHZ14LBC

Ord.

Q'ty

4 Open Panel Assy 9314405037

1 Air Filter 9313859015

3 Front Panel Assy 9313882044

5 Top Grill 9313848019

6 Top Cover 9313849023

2 Dust Box Assy 9313884024

7 Under Cover 9313850029

9 Casing Assy 9313877019

10 Louver U Assy 9312243037

11 Louver U 9311993032

12 Louver Frame 9311994015

13 Spring EL 9312194001

14 Louver Z 9311996033

15 Spring F 9314143014

16 Diffuser U 9313856014

17 Diffuser Z 9313857011

18 Spring C 9314142017

19 Casing Cover F 9313839017

20 Casing Cover B 9313838010

21 Casing Cover L 9313887018

22 Casing Cover R 9313888015

24 Louver Cam 9312000012

25 Tension A 9312197002

26 Spring Holder 9311999010

27 Gear A 9309994003

28 Drain Hose Assy 9314147012

29 Drain Cap Assy 9304150008

30 Evaporator Assy 9314110016

31 Evaporator Assy B 9312213023

32 Evaporator Assy C 9312465026

33 Joint Pipe Assy 9314111020

36 Senser Case 9313843014

37 Sensor Cover 9313853013

40 Motor Cover 9313840013

41 Crossflow Fan Assy 9312004010

42 Bearing C Assy 9306628017

43 Control Box 9312005017

44 Controll Cover 9312006014

46 Receiver Case 9313842017

AWHZ18LBC

23 Bushing-A

Part No.

9303529010

47 Cord Clamp 9302271002

48 Evaporator Holder R 9313833015

49 Evaporator Holder L 9313834012

50 Rear Bracket 9312416011

51 Controller PCB Assy 9707170016

52 Power Cord Assy 9900339029

53 Display Assy 9705808027

54 Fan Motor Assy 9601888017

56 Stepping Motor U 9703477010

57 Stepping Motor Z 9305780006

58 Connector w/Wire S 9314144011

60 UV Unit Assy 9314153013

61 Remote Controller Assy 9314157035

62 Gear Box Assy 9313880019

--- Room Temp. Thermistor 9700801139

--- Pipe Temp. Thermistor 9702039042

--- Fuse 3A 0600376062

--- Relay 9704185013

9314405037

9313859015

9313882044

9313848019

9313849023

9313884024

9313850029

9313877019

9312243037

9311993032

9311994015

9312194001

9311996033

9314143014

9313856014

9313857011

9314142017

9313839017

9313838010

9313887018

9313888015

9312000012

9312197002

9311999010

9309994003

9314147012

9304150008

9314110016

9312213023

9312465026

9314111020

9313843014

9313853013

9313840013

9312004010

9306628017

9312005017

9312006014

9313842017

9303529010

9302271002

9313833015

9313834012

9312416011

9707170023

9900339029

9705808027

9601888017

9703477010

9305780006

9314144011

9314153013

9314157035

9313880019

9700801139

9702039042

0600376062

9704185013

2006.02.06 14
