2006.02.27 16
STANDARD ACCESSORIES
The following installation accessories are supplied.
Use them as required.
Name and Shape Q'ty Name and Shape Q'ty
Wall hook bracket
9312011018
9314157035
0600185046
9312947010
9303029022
9308117007
0700076046
0700019036
9304536000
Remote control unit
Battery
Tapping screw (big)
Drain pipe
Cloth tape
1
1
2
8
1
1
1
2
Tapping screw (small)
Remote control unit
holder
Seal A
1
