General-Fujitsu AWHZ24LBC [14/27] Outdoor unit power supply pcb assembly k05cw 0603hue fl0
![General-Fujitsu AWHZ24LBC [14/27] Outdoor unit power supply pcb assembly k05cw 0603hue fl0](/views2/1804969/page14/bge.png)
12V
K101
DW12D1
3
2
4
1
C108
3.3
<LE>
L102
N200500K1D7C
C107
1.0 <LE> - M
12V
B
B
B
B
R100 ZPR0RCH400 PTC THERMISTOR
R101 ZPR0RCH400 PTC THERMISTOR
CN100
172520-2
POWER RELAY CONTROL
W29
BROWN
W28
ORANGE
W26
ORANGE
W25
ORANGE
PTC OUT
C106
3.3
<LE>
C109
1000P
<E>
C110
1000P
<E>
L101
SC - 18 - 15JH
4 3
1
2
CT OUT
W21
GRAY
B
W9
BLACK
L100
SC - 18 - 15JH
C103
3.3
<LE>
C104
0.033
<YE>
C100
3.3
<LE>
VA100, VA101
470V <TNR>
SA100
RA - 302M
4 3
1
2
B
B
B
B
B
B
B
F100
FSL 10A - 250V
FH100
PFC5000
- 0502
FH101
PFC5000
- 0502
W17
BLACK
W18
WHITE
W2
WHITE
W3
GREEN
W19
BLACK
W20
WHITE
or
TO INDOOR UNIT
N
L
L
N
L
W1
BLACK
EARTH
AC VOLT OUT
B
OUTDOOR UNIT
POWER SUPPLY PCB ASSEMBLY
K05CW-0603HUE-FL0
C105
0.033
<YE>
2006.10.18 13
