General-Fujitsu ARG60AUAK [3/24] Outline and dimensions
![General-Fujitsu ARG60AUAK [3/24] Outline and dimensions](/views2/1804984/page3/bg3.png)
OUTLINE AND DIMENSIONS
Models : ARG60AUAK
(Unit : mm)
ARG60RUAK
INDOOR UNIT
AIR
AIR
AIR
1,050 mm
1,000 mm
395 mm
155 mm
585 mm
500 mm
1,080 mm
85 mm
2004.06.30 2
