![General-Fujitsu ASG17USCQ [4/18] Refrigerant system diagram](/img/pdf.png)
General-Fujitsu ASG17USCQ [4/18] Refrigerant system diagram
![General-Fujitsu AOG17UNBK [4/18] Refrigerant system diagram](/views2/1806378/page4/bg4.png)
REFRIGERANT SYSTEM DIAGRAM
ASG17FSCQ / AOG17FNBN
Models : ASG17FSBQ / AOG17FNBK
Refrigerant pipe
12.70 mm (1/2")
Refrigerant pipe
6.35 mm (1/4")
Charging v
Distributor
Distributor
Distributor
Distributor
alve
INDOOR UNIT
Evaporator
Capillary tube
Compressor
Strainer
OUTDOOR UNIT
ASG17USCQ / AOG17UNBN
Models : ASG17USBQ / AOG17UNBK
Cooling
Heating
Flare coupling
Refrigerant pipe
12.70mm(1/2")
Refrigerant pipe
6.35mm(1/4")
INDOOR UNIT
Strainer
Strainer
Charging valve
4-Way
valve
Compressor
Capillary
tube
OUTDOOR UNIT
Condenser
Distributor
Muffler
32005.01.14
Condenser
Evaporator
