General-Fujitsu AWG14UBBJ [2/24] S p e c i f i c a t i o n s
![General-Fujitsu AWG14UBBJ [2/24] S p e c i f i c a t i o n s](/views2/1806460/page2/bg2.png)
1
2004.07.13
SPECIFICATIONS
TYPE COOL & HEAT
INDOOR UNIT AWG14UBBJ
OUTDOOR UNIT AOG14USBJ
COOLING CAPACITY
(kW)
(kW)
4.20
HEATING CAPACITY 4.60
POWER SOURCE (V) 230
FREQUENCY (Hz) 50
RUNNING
(A)
COOLING 6.5
CURRENT
HEATING 5.7
INPUT
(kW)
COOLING 1.45
WATTS
HEATING 1.28
E.E.R. (kW/kW)
COOLING 2.90
HEATING 3.59
MOISTURE REMOVAL 1.6
AIR CIRCULATION-Hi
( /hr)
(m
3
/hr) 650
ELECTRICAL DATA
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE
Hermetic type, Deposit electrode condenser,
2 poles, Single phase, Induction motor, Rotary
DISCRIMINATION 80236035B
REFRIGERANT R410A (g) 1,150
POWER SOURCE (V) 230
DISCRIMINATION MFD-30HO
INDOOR
HI-SPEED
HI-SPEED
( r.p.m. ) 1,000
UNIT
MED-SPEED ( r.p.m. ) 910
LO-SPEED ( r.p.m. ) 820
OUTDOOR
DISCRIMINATION MFB-14NTT
UNIT
( r.p.m. ) 750
INDOOR UNIT H x W x D 270 x 1,150 x 285
OUTDOOR UNIT
(mm)
H x W x D
(mm)
530 x 750 x 250
WEIGHT
INDOOR UNIT
GROSS / NET
20 / 16
OUTDOOR UNIT
(kg)
GROSS / NET
(kg)
37 / 35
1,150 g (40.6 oz)
1,187 g (41.9 oz)
1,262 g (44.5 oz)
15 g (0.53 oz) / 1 m (3.3 ft)
(over 7.5 m)
7.5 m (25 ft)
10 m (33 ft)
15 m (49 ft)
Additional refrigerant
FULL CHARGE
AMOUNT
REFRIGERANT CHARGE (R-410A)
PIPE LENGTH
