Model: HSU-09H03/Z1
Cooling capacity(W)
2300
Heating capacity(W)
2600
Cooling coefficient(W/W) 2.77 Heating coefficient(W/W) 3.33
Cooling power input(W) 830 Heating power input(W) 780
Moiture removal(m /h)
3
1.36X10
-3
Refrigerant type R22
Operating voltage range (V ) 220~ Frequency range(Hz) 50
Operating temp. range (
O
C ) -7-43
Air sending angle 60
O
indoor unit
Cross flow fan
Variation of temp. adjust (
O
C ) + 1
Fan type
outdoor unit
Axial flow fan
Climate type: T1 Class of electric shock I
Indoor unit noise
37/35/30
Outdoor unit noise 48
Net dimensions mm
(
indoor unit
)
795*199*265
Net dimensions mm
(
outdo
or unit)
745*315*428
Packaging dimensions mm
(
indoor unit
)
863*277*339
Packaging dimensions mm
(
outdoor unit
)
843*359*515
Net/gross weight (kg)
(
indoor unit
)
7.2/10.2
Net/gross weight (kg)
(outdoor unit)
31/36
indoor unit 8Max. mounting height
difference(m)
5
Piling layers
outdoor unit 4
Refrigerant charge(g)
R22
540
Current entering side
(
indoor/outdoor
)
Indoor
Frequency of filter cleaning Once/2 weeks Compressor manufacturer RECHI
Compressor model 44R233BF-5JS Compressor oil type
Compressor oil charge (cc) 270 Compressor protector type MRA99254L-9054
Maxi. length of connecting
p
i
p
e
(
m
)
7
length(mm) 2000
Refrigerant recharged(Length
of connectin
g
p
i
p
e is more
20g per meter
drain hose
diametre(mm) 16
Cap. tube type muffle
model:
TP2Y Type of tube of evaporator
and condense
r
Internal treaded
Fan speed(H/M/L)(r/min)
(indoor unit)
1150/1100 / 920 Size of tube of evaporator and
condenser
(
mm
)
Dia. 7 / 9.52
Fan speed(r/min)
(outdoor unit)
860 Appearance features of indoor
unit
Large arc plastic
two-way 1/4
Cut-off vavle(inch)
three-way 3/8
Appearance features of outdoor
unit
Mini type
Max. operating pressure at
warm side(Mpa)
2.65
Max. operating pressure at cool
side(Mpa)
2.65
Domestic Air Conditioner Model: HSU-09H03/Z1
HSU-12H03/Z1
6
Содержание
- Domestic air conditioner 1
- Features 1
- Hsu 09h03 z1 1
- Hsu 12h03 z1 1
- Models 1
- Service manual 1
- Content 2
- Comfortable wide angle airflow 3
- Convenience 3
- Engergy efficient 3
- Health air purifying 3
- Night set models 3
- Program dry 3
- Quiet operation 3
- Wide variety of functions 3
- Description of product model coding and series introduction 4
- 3 4 5 6 7 1 8 5
- A description of coding rules of unit model coding rules and descriptions are as follows 5
- B standard situation conditions 5
- Examples hsu 0 9r04 it represents wall mounted split type heat pump air conditioner the cooling capacity is 9 000btu h and the power supply is 2 4 0v 50hz 5
- Introductory remarks 5
- Specifications 6
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 7
- Model hsu 09 h03 z1 7
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 8
- Model hsu 12 h03 z1 8
- Curves of performance 9
- Curves of cooling capacity and heating capacity as a function of outdoor temperatur 10
- Ambient temperature 11
- Domestic air conditioner domestic air conditioner 11
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 11
- Model 44r233b 8 11
- Performance curve 11
- Power supply 220v 50hz 1ph 11
- Rechi precision co ltd 11
- Return gas temperature 11
- Subcooling 11
- Capacity w curent a 12
- Condensing temperature 12
- Curves of compressor performance compressor rh220vhlc 12
- Evaporating temp 12
- Flow rate kg h 12
- Input w 12
- Description dimension and function of main components and accessories 13
- Indoor unit net dimensions 15
- Outdoor unit net dimensions 15
- Knock down drawings 16
- Domestic air conditioner domestic air conditioner 17
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 17
- No parts code name of part part qty easily damaged components y n 19
- No parts code name of part part qty easily damaged components y n 21
- No parts code name of part part qty easily damaged components y n 22
- Brief introduction to electrical 23
- Control function 23
- Domestic air conditioner domestic air conditioner 24
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 24
- Function schedule 24
- 2 indoor temperature control compressor off 25
- 3 dehumidification running 25
- Brief introduction to electrical control function 1 introduction to electrical control function 25
- Compressor off 25
- Compressor on 25
- Heating 25
- Setting temperature 25
- Setting temperature refrigerating 25
- Brief introduction to electrical control function brief introduction to electrical control function 26
- 10 compensatory function of power failure 27
- 7 freezing prevention function 27
- 8 3 minutes stand by time 27
- 9 overload protection during heating running 27
- 11 trial run function 28
- 12 emergency running mode 28
- 13 temperature compensation 28
- 14 sleeping function 28
- Brief introduction to electrical control function 28
- Wiring diagram 30
- Wiring diagram for indoor unit 31
- Wiring diagram for oudoor unit 31
- Circuit diagram 32
- Domestic air conditioner domestic air conditioner 33
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 33
- Abnormity diagnose 34
- Abnormality diagnosing 35
- Trouble shooting 36
- Refrigerating cycle diagram 38
- Air velocity distribution 40
- Noise level test chart 40
- Installation manual 43
- Installation manual 44
- Connecting the indoor outdoor electric cable 48
- Removing the wiring cover 48
- When connecting the cable after installing the indoor unit 48
- When connecting the cable before installing the indoor unit 48
- Attaching drain elbow 49
- Connection 49
- Connection of pipes 49
- Domestic air conditioner domestic air conditioner 49
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 49
- Drawing for the installation of indoor and outdoor units 49
- Flare nut 49
- Half union 49
- Install according to 49
- Installation of outdoor unit 49
- Note only for heat pump unit 49
- Spanner torque wrench 49
- To bend a pipe give the roundness as large as possible not to crush the pipe and the bending radius should be 30 to 40 mm or longer connecting the pipe of gas side first makes working easier the max vertical distance between the indoor unit and the outdoor unit is 5 m 49
- Additional amount 50
- Domestic air conditioner domestic air conditioner 50
- Domestic air conditioner model hsu 09h03 z1 hsu 12h03 z1 50
- M 7m 10m 50
- No need 32g 50
- Piping length 50
- Purging method 50
- Haier group 52
- Sincere forever 52
