Functions and control
Domestic Air Conditioner
-8 138.9148 127.4956 116.8717 -1.53 1.43
-7 130.9337 120.3778 110.5374 -1.51 1.41
-6 123.4597 113.7009 104.5852 -1.49 1.39
-5 116.4577 107.4349 98.9897 -1.47 1.38
-4 109.8953 101.5523 93.7278 -1.45 1.36
-3 103.7422 96.0274 88.7774 -1.43 1.34
-2 97.9708 90.8365 84.1185 -1.40 1.32
-1 92.5551 85.9574 79.7322 -1.38 1.30
0 87.4712 81.3697 75.6011 -1.36 1.29
1 82.6970 77.0544 71.7088 -1.34 1.27
2 78.2118 72.9937 68.0402 -1.31 1.25
3 73.9966 69.1712 64.5813 -1.29 1.23
4 70.0335 65.5716 61.3188 -1.27 1.21
5 66.3062 62.1807 58.2405 -1.24 1.19
6 62.7992 58.9853 55.3351 -1.22 1.17
7 59.4984 55.9729 52.5917 -1.20 1.15
8 56.3905 53.1320 50.0006 -1.17 1.13
9 53.4631 50.4521 47.5523 -1.15 1.11
10 50.7048 47.9230 45.2384 -1.13 1.09
11 48.1049 45.5355 43.0505 -1.10 1.07
12 45.6534 43.2808 40.9813 -1.08 1.04
13 43.3410 41.1509 39.0236 -1.05 1.02
14 41.1592 39.1381 37.1708 -1.03 1.00
15 39.0998 37.2355 35.4167 -1.00 0.98
16 37.1553 35.4363 33.7555 -0.98 0.96
17 35.3186 33.7344 32.1818 -0.95 0.94
18 33.5833 32.1240 30.6905 -0.93 0.91
19 31.9432 30.5997 29.2769 -0.90 0.89
20 30.3925 29.1565 27.9365 -0.88 0.87
21 28.9259 27.7895 26.6651 -0.85 0.84
22 27.5383 26.4944 25.4589 -0.83 0.82
23 26.2252 25.2670 24.3140 -0.80 0.80
24 24.9822 24.1034 23.2271 -0.78 0.77
25 23.8050 23.0000 22.1950 -0.78 0.77
26 22.7500 21.9499 21.1520 -0.78 0.78
27 21.7477 20.9536 20.1638 -0.82 0.81
28 20.7951 20.0081 19.2272 -0.86 0.85
29 19.8895 19.1104 18.3394 -0.89 0.88
30 19.0285 18.2581 17.4974 -0.93 0.92
31 18.2094 17.4484 16.6988 -0.97 0.95
32 17.4302 16.6792 15.9410 -1.00 0.99
33 16.6885 15.9480 15.2217 -1.04 1.02
34 15.9825 15.2530 14.5389 -1.08 1.06
35 15.3103 14.5920 13.8903 -1.12 1.09
36 14.6700 13.9632 13.2743 -1.16 1.13
HSU-07 09 12L HEK03
22
