Chapter 1
2
BSWI-D2 USER MANUAL
SoC
Specifications
• Signal channel DDR3L SO-DIMM memory architecture
• 1 x 204-pin DDR3L SO-DIMM socket supports up to 8 GB
• Supports DDR3L 1600 MHz DDR3 SDRAM
Memory
• 1 x M.2 slot
include PCI-E x 1 & USB signal, support 2230(A/E key) WiFi/BT
• Supported by Intel
®
Braswell SoC
- 2 x Serial ATA 6Gb/s devices
Storage
Rear Panel I/O
LAN • Realtek RTL8111H Gigabit LAN
• Realtek ALC662 6-CH HD Audio CODEC
- 6 Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio
• Onboard Intel
®
Braswell Refresh Pentium J3710/Celeron
J3160/Celeron J3060 or other SoC
• Supports TDP up to J3710(6.5W), J3160/J3060(6W)
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x 2*5-pin USB 2.0 header supports additional two USB 2.0
ports
• 1 x 1*5-pin USB 2.0 header supports additional one USB 2.0
port
• 2 x Serial ATA 6Gb/s connectors
• 1 x BZ
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x Case open header
• 1 x Parallel port header (LPT)
• 1 x TPM header
• 1 x EMMC header
• 2 x COM headers
Internal I/O
Connectors &
Headers
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x PS/2 Keyboard & PS/2 Mouse connectors
• 1 x D-sub (VGA) port
• 1 x COM port
• 1 x HDMI port
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 1 x Audio port (1 x line-in, 1 x line-out, 1 x Microphone)
Expansion
Slots
