3. Dismantle air filter

CAUTION!

4. Clean

6. Close inlet grill

7. Press the filter signal return key on the

controller.

(A) Remove dust with vacuum filter.

5. Install air filter

(1) Put filter into protruding parts at the top of

the inlet grill.

(2) Connect the two pothooks with inlet grill

See 2

[Clean inlet grill]

1. Open inlet grill

See 1.

Connet the two pothooks with inlet grill

PUSH

Press the elliptical knob

the inlet grill will

automatically drop

Open two

pothooks

Pothook

Press the elliptical "PUSH" knob, the inlet

grill will automatically drop. (the inlet grill

is catched with two pothooks)

Drag the knob of

the grill back lift

the filter and take

down.

Air filter

'' ''

Maintenance

[Clean air filter]

NOTE

1. Open inlet grill

Press the elliptical "PUSH" knob, the inlet

grill will automatically drop. (the inlet grill

is catched with two pothooks)

When having to clean, don't dismantle

air-filter,otherwise may cause faults.

In the environment where there is too

much dust, air filter should be cleaned

for more times.

(about half a year one time)

2. Open two othooks

(B) Wash with water.

With too much dust, use soft brush and neutral

detergent.

Swing off the water, and then place in cool place.
