>_]]VbTZR\ <Zb >_^UZdZ_^Vb
-20-
coolin
g
heatin
g
kW 6.8(2.0--7.6) 7.1(3.0--8.3)
0.72 /
10‐³×m³/h
r/min
kW
m³/h
Pa
mm
m²
℃
External
（L×W×H）
mm×mm×mm
Package
（L×W×H）
mm×mm×mm
mm
dB(A)
dB(A)
kg / kg
Refrigerant
mm
mm
Norminal condition: indoor temperature (cooling): 27℃DB/19℃WB, indoor temperature (heating): 20℃DB
Outdoor temperature(cooling): 35℃DB/24℃WB, outdoor temperature(heating): 7℃DB/6℃WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser
calibrated sound intensity meter. It is a sound pressure noise level.
PIPING
Type
R410A
Pipe
Liquid
9.52
Gas
15.88
Connecting Method
flared
Noise level ---sound power (H-M-L) 60/56/52/48
Weight (Net / Shipping) 25.2/28.4
Noise level ---sound presure (H-M-L) 49/45/41/37
Control type (Remote / Wired) wired,YR-E14
Dimension
1090*500*220
1174*549*294
Drainage pipe (material , I.D./O.D.) 20/24
Static pressure 25
Heat exchanger
Type / Diameter inner grooved pipe/φ7
Total Area 0.51
Temp. scope 2-7
1250±40/1130±40/1000±50/850±50
Fan motor output power 0.05
Air-flow(H-M-L) 1200/1050/850(white terminal 0 Pa)
Sensible heat ratio
Dehumidifying capacity 2.2
Indoor unit
Power Supply 1PH,220-230V 50-60HZ
Fan
Type × Number CENTRIFUGALX2
Speed(H-M-L)
Item Model
AD24LS1ERA
Function
Capacity
