5.1.3. Switch setting and functions:
>_]]VbTZR\ <Zb >_^UZdZ_^Vb
Outdoor main PCB 0151800075
SW5 definition
12345678 definition
ON --- --- --- --- --- --- --- cooling only
OFF --- --- --- --- --- --- --- heat pump (default)
--- ON --- --- --- --- --- --- set ON if frost easily
--- OFF --- --- --- --- --- --- set OFF if hard to frost(default)
--- --- ON --- --- --- --- --- Max. running current is 11A
--- --- OFF --- --- --- --- --- normal control (default)
--- --- --- OFF OFF ON --- --- 3U19*
--- --- --- OFF ON ON --- --- 4U25*
--- --- --- ON OFF ON --- --- 4U30*
--- --- --- ON ON OFF --- --- 5U34*
--- --- --- --- --- --- ON --- temperature correction valid
--- --- --- --- --- --- OFF --- temperature correction null
--- --- --- --- --- --- --- ON quiet operation valid
--- --- --- --- --- --- --- OFF quiet operation null
-76-
outdoor unit
address
0000 12345
1000 678910
0100 11 12 13 14 15
1100 16 17 18 19 20
0010 21 22 23 24 25
1010 26 27 28 29 30
0110 31 32 33 34 35
1110 36 37 38 39 40
0001 41 42 43 44 45
1001 46 47 48 49 50
0101 51 52 53 54 55
1101 56 57 58 59 60
0011 61 62 63 64 65
1011 66 67 68 69 70
0111 71 72 73 74 75
1111 76 77 78 79 80
indoor unit address
Note: "0" means the dip switch is "OFF"; "1" means the
SW6: outdoor central control address setting
dip switch is "ON"
Small service PCB:0151800076
SW1 definition:
SW7: pre-set dip switch
1234
OFF OFF OFF OFF
ON OFF OFF OFF
OFF ON OFF OFF
OFF OFF ON OFF
OFF OFF OFF ON
ON ON ON ON
rated operation
time defrost valid
detection for wrong wiring
definition
state when out of factory
compulsory heating: 50HZ, outdoor motor 5-class,
standard open angle 200, the others are normal
compulsory cooling: 60HZ, outdoor motor 7-class,
standard open angle 200, the others are normal
