Lenovo ThinkPad X200 Tablet [176/260] Rear view

Rear view

1 Status indicators

Note: For the description of each indicator, see “Status indicators” on page

71.

2 ExpressCard slot

3 Wireless radio switch

4 Universal Serial Bus (USB) connector

5 RJ-45 (Ethernet) connector

6 External monitor connector

7 AC power connector

8 Security key hole

Rear view (tablet mode)

1 Tablet buttons

2 Fingerprint reader

3 Status indicators

Note: For the description of each indicator, see “Status indicators” on page

71.

168 ThinkPad X200 Tablet and X201 Tablet Hardware Maintenance Manual
