Haier HCFU-18CC03 Сервис мануал онлайн
HCFU-14C03 ( AC142ACMAA+AU142AFMAA)
HCFU-18CC03 ( AC182ACMBA+AU182AFMBA)
MANUAL CODE: SYJS-006 EDITION:2002.12.31.
Haier Group
Auto-restart function
Group control(with a group controller)
Auto-changeover
Compact design of indoor unit
Weekly timing(with a weekly timer)
With new environment friendly refrigerant R407C
Features
Service Manual
Commercial Air Conditioning
Convertible Type R22 Cooling Only Series
HCFU-36C03 ( AC36NACMAA+AU36NAIMBA)
HCFU-42CC03 ( AC42NACMCA+AU42NAIMBA)
HCFU-28CC03 ( AC282ACMBA+AU28AHMCA )
