The followingthingsshould be checked before starting the dishwasher.
The content of this manual is very he lpfulto the users.
After installation, please make sure to keep this manual.
1
The dishwasher is level and fixed properly
2
T he i nle t va lv e i s o pen
3
There is a leakage at theconnections ofthe conducts
4
The wires aretightly connected
5
The poweris switched on
6
The inl et an d dr ain ho ses are kno tte d
7
All packingmaterials andprintings should be taken out from the dishwasher
Extension Hose
Ifyouneeda drainhoseextension, make sure touse a similar drain hose.
It must b e no longer than 4 metres; ot herw ise the cleani ng eff ect of the dishw as her coul d be reduced .
Wa t e r O u t l e t
Connect the wat er d rain h os e. Th e dr ain h ose mu st be cor rectly fit tedt o avoi dwate r lea ks.
Ensur e t hat th ew ate r dra in h ose i s no t kin ked or s quashed .
I f the si nk is 1 000 h igh er f rom t he floor, t he exc ess w a ter in hoses cannot be dr aine d di rec tly
into the sink.Itwillbe necessary todrainexcesswaterfrom hoses into abowlorsuitable
conta ine r that is held out side and lower th ant hes ink.
How to Drain Excess Water From Hoses
Syphon Connection
Th e w ast e connec ti on must be at a height le s s t han 100 0 m m (maxi mu m) f rom t hebottom o f the di s h.
The w at er dr ain h ose sho uld be fi xed .
Insert th e drai nh ose into adr ain p ipe with a m inimum di am eter of 4 0mm , or l et i t run into the sink , mak ing sur eto
avoid bendingor crimpingit.The topof the hosemust belessthan 1000mm.
A
Counter
Front
Drain pipe
NOTE
The top of the hose
must be l ess than
1000mm.
φ 40m m
B
17
