Haier HSU-09H03/H(DBP) [6/26] Parts and functions
![Haier HSU-09H03/H(DBP) [6/26] Parts and functions](/views2/1810028/page6/bg6.png)
Air Conditioner
Edition:2006/1/10
3
Outdoor unit
Parts and Functions
Indoor unit
12
OUTLET
CONNECTING PIPING AND ELECTRICAL WIRING
INLET
1
2
DRAIN HOSE
4
Display board
The conversion of pilot light's colors will be displayed as
the figure under different operation models
OPERATE
RED
RED
GREEN
GREEN
GREEN
YELLOW
COOL DRY HEAT TIMER HEALTH
Display board
Inlet
Anion generator
Vertical flap
(Use remote controller to
adjust up and down air flow.
Don't adjust it manually)
Horizontal louver
Air filter
Inlet grille
(inside)
(adjust left and right air flow)
(inside)
