Back View
Main Filter
Dete rgent Dispenser
Cup Shelf
Cutlery Basket
Coarse Filter
Rinse Aid Dispenser
Inlet pipe connector
Drain pipe connector
Lower Baske t
Spra y Arms
Upper Basket
1
Salt Container
before using it for the first tim e.
To get the best performance from your dishwasher, read all operating instructions
5
6
7
8
9
10
12
11
3
2
4
1
2
3
4
5
6
7
8
9
10
on
Of f
Front view
Power on light: To come on when Power ON/OFF
button is pressed down.
ON/OFF Button: To turn on/off the power supply.
Progr am Key-press:To selec t washing program
when press the Key-press.
Vorwah Button: Press this button to set the
del ayed hours for washing. You can delay the start
of wash ing up to 24 hours. One press on this
but ton delays the start of washing by one hour.
Display Window: delay time, running indicator,
faut codes, program option, salt- and rinse aid
shortage
Pr og.
Ein
Aus
Vorw ahl
GSPE 77 2.1
.
Содержание
- For detailed operating method read the corresponding content on the instruction manual 2
- If there is no salt warning light in the control panel for some models you can estimate when to fill the salt into the softener by the number of cycles the dishwasher has run 2
- Attention before or after loading the dishwasher baskets 3
- B loading the salt into the softener 3
- Caring for the dishwasher 6 3
- Change the programme 4 3
- Cutlery basket 2 3
- D function of detergent 3
- Dear customer 3
- Error codes 6 3
- Filtering system 5 3
- Keep it to refer to it at a later date 3
- Loading the lower 0 basket 3
- Pass it on to any subsequent owner of the appliance 3
- Please carefully read this manual before using the dishwasher it will help you to use and maintain the dishwasher properly 3
- The manufacturer following a policy of constant development and updating of the product may make modifications without giving prior notice 3
- This appliance is intended to be used in household and similar applications such as staff kitchen areas in shops offices and other working environments farm houses by clients in hotels motels and other residential type environments bed and breakfast type environments 3
- This manual contains sections on safety instructions operating instructions installation instructions and troubleshooting tips etc 3
- To review the section on troubleshooting tips will help you to solve some common problems by yourself 3
- Turning on the appliance 4 3
- Wash cycle table 3 3
- During installation the power supply must not be excessively or dangerously bent or flattened 4
- Improper connection of the equipment grounding conductor can result in the risk of an electric shock check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded do not modify the plug provided with the appliance if it does not fit the outlet have a proper outlet installed by a qualified electrician 4
- Use only detergent and rinse additives designed for an automatic dishwasher never use soap laundry detergent or hand washing detergent in your dishwasher keep these products out of the reach of children 4
- When using your dishwasher follow the precautions listed below 4
- Always use the salt intended for use with dishwasher the salt container is located beneath the lower basket and should be filled as explained in the following 8
- Attention 8
- Function of rinse aid 8
- Only use salt specifically designed for the use in dishwashers every other type of salt not specifically designed for the use in a dishwasher especially table salt will damage the water softener in case of damages caused by the use of unsuitable salt the manufacturer does not give any warranty nor is liable for any damages caused only fill with salt just before starting one of the complete washing programs this will prevent any grains of salt or salty water which may have been spilled remaining on the bottom of the machine for any period of time which may cause corrosion 8
- Rinse aid dispenser 8
- The salt container must only be refilled when the salt warning light in the control panel comes on depending on how well the salt dissolves the salt warning light may still be on even though the salt container is filled if there is no salt warning light in the control panel for some models you can estimate when to fill the salt into the softener by the cycles that the dishwasher has run 2 if there are spills of the salt a soak or a rapid program should be run to remove the excessive salt 8
- Adjusting rinse aid dispenser 9
- Detergents 9
- Detergents with its chemical ingredients are necessary to remove dirt crush dirt and transport it out of the dishwasher and dry don t put powder detergent into the dispenser until you re ready to wash dishes use only detergent specifically made for use in dishwashers keep your detergent fresh 9
- Don t forget to replace the cap before you close dishwasher door 9
- Proper use of detergent 9
- There are 3 sorts of detergents 1 with phosphate and with chlorine 9
- When to refill the rinse aid dispenser 9
- Without phosphate and without chlorine 9
- Amount of detergent to use 10
- Concentrated detergent 10
- Detergent dispenser 10
- Detergent tablets 10
- Fill in detergent 11
- Are not suitable are of limited suitability 12
- Adjusting the upper basket 15
- Folding spikes of lower basket 15
- Express 16
- For heaviest soiled crockery and normally soiled pots pans dishes etc with dried on soiling 16
- For lightly soiled crockery and glass 16
- For lightly soiled loads that do not need excellent drying efficiency 16
- Means need to fill rinse into the rinse aid dispenser 16
- Multi tab 16
- Pre wash 50 wash 65 rinse rinse rinse 55 drying 16
- Rinse rinse 50 drying 16
- Standard daily cycle for normally soiled loads such as pots plates glasses 16
- A cycle that is underway can only be modified if it has only been running for a short time otherwise the detergent may have already been released and the appliance may have already drained the wash water if this is the case the detergent dispenser must be refilled see the section entitled loading the detergent open the door p the prog more than 3 seconds to cancel the current program you can choose a desired cycle setting 17
- Open the door carefully 17
- Switch off the dishwasher 17
- Unloading the dishwasher 17
- Filter assembly 18
- Cleaning the door 19
- Cleaning the filter 19
- Cleaning the spray arms 19
- It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings to remove the spray arms screw off the nut clockwise to take out the washer on top of the spray arm and remove the arm wash the arms in soapy and warm water and use a soft brush to clean the jets replace them after rinsing them thoroughly 19
- Protect against freezing 19
- Remarks 19
- The entire filter assembly should be cleaned once a week 19
- When cleaning the filters don t knock on them otherwise the filters could be contorted and the performance of the dishwasher could be decreased 19
- After every wash 20
- If the appliance must be moved try to keep it in the vertical position if absolutely necessary it can be positioned on its back 20
- Installation preparation 20
- Moving the appliance 20
- No solvents or abrasive cleaning 20
- Remove the plug 20
- When not in use for a longtime 20
- Figure3 21
- Figure4a 22
- Connection of drain hoses 23
- Figure5 23
- Tension adjustment of the door spring 23
- Dishwasher installation steps 24
- Figure 7 24
- Dishwasher must be level for proper dish rack operation and wash performance 25
- Figure 8 25
- Illustration of feet adjustment 25
- Level the dishwasher by adjusting the four leveling legs individually 25
- Note the maximum adjustment height of the feet is 60 mm 25
- Place level on door and rack track inside the tub as shown to check that the dishwasher is level 25
- Warning 25
- When level the dishwasher please pay attention not to let the dishwasher tip over 25
- A hose that attaches to a sink spray can burst if it is installed on the same water line as the dishwasher if your sink has one it is recommended that the hose be disconnected and the hole plugged 26
- Connect the cold water supply hose to a threaded 3 4 inch connector and make sure that it is fastened tightly in place if the water pipes are new or have not been used for an extended period of time let the water run to make sure that the water is clear and free of impurities if this precaution is not taken there is a risk that the water inlet can get blocked and damage the appliance 26
- Extension hose 26
- How to drain excess water from hoses 26
- Positioning the appliance 26
- Syphon connection 26
- The safety supply hose consists of the double walls the hose s system guarantees its intervention by blocking the flow of water in case of the supply hose breaking and when the air space between the supply hose itself and the outer corrugated hose is full of water 26
- Water outlet 26
- Use only the special dishwasher detergent to avoid suds if this occurs open the dishwasher and let suds evaporate add 1 gallon of cold water to the tub close and latch the dishwasher then select any cycle dishwasher will drain out the water at the first step open the door after draining is stop and check if the suds is disappeared repeat if necessary 28
- If overflow occurs turn off the main water supply before calling a service if there is water in the base pan because of an overfill or small leak the water should be removed before restarting the dishwasher 29
- When some malfunctions come on the appliance will display error codes to warn you 29
- Technical data sheet 31
