INSTALLATION
PAGE 8
ENGLISH
for
operation, etc.)
A
TING INS TRUC TIONS carefully .
Section 7 - Explaining Operation to the End User
Section 9 - Seacoast Application
the unit installed from ½ mile to 5 miles a way from the salt water, including seac oasts and inland w aterways, please f ollow the
installation instruction below.
ODU
ODU
Sea breeze
Sea
ODU
Sea breeze
Sea
ODU
Sea breeze
Sea
Protection walls
ODU
the outdoor unit.
ze.
concrete to block the sea bree ze and the height and the width of the w all
should be 1.5 times larger than the size of the outdoor unit. Also , secure
over 28 in (700mm) bet ween the protection wall and the outdoor unit f or
exhausted air to ventilate.
to clean the sea w ater and the
dust on the outdoor unit heat e xchanger.
Model Name
SE42SE81SE21SE90metsyS
Outdoor 1U09ES2VHA 1U12E S2VHA 1U18ES2VHA 1U24ES2VHA
Indoor
AW09ES2VH*
AW12ES2VH* AW18ES2VH*
AW24ES2VH*
Operating Range
Cooling °F(°C) 14~115(-10~46) 14~115(-10~46) 14~115(-10~46) 14~115(-10~46)
Heating °F(°C) -4-75(-20-24) -4-75(-20-24) -4-75(-20-24) -4-75(-20-24)
Power Supply Voltage, Cycle, P hase V /Hz/- 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Electrical Data
yratoR nevirD retrevni CDepyT rosserpmoC
Maximum F use Size A 15 15 30 30
Minimum Circuit Amp A 15 15 18 21
R efrigerate Line
Connections Flare Flare Flare Flare
Liquid O.D. in 1/4 1/4 1/4 1/4
Suction O.D. in 3/8 3/8 1/2 1/2
Factory Charge O z 38.8 38.8 52.2 74.1
Maximum Line Length F t / m 50/15 50/15 83/25 83/25
Maximum Height F t / m 33/10 33/10 50/15 50/15
Model Name
4TE28TE12TE19TE0metsyS
Outdoor
Indoor
Operating Range
Cooling °F(°C) 14~115(-10~46) 14~115(-10~46) 0~115(-18~46) 0~115(-10~46)
Heating °F(°C) -4-75(-20-24) -4-75(-20-24) -4-75(-20-24) -4-75(-20-24)
Power Supply Voltage, Cycle, P hase V /Hz/- 115/60/1 115/60/1 208-230/60/1 208-230/60/1
Electrical Data
yratoR nevirD retrevni CDepyT rosserpmoC
Minimum Circuit Amp A 18 18 17 19
R efrigerate Line
Connections Flare Flare Flare Flare
Liquid O.D. in 1/4 1/4 1/4 1/4
Suction O.D. in 3/8 3/8 1/2 1/2
Factory Charge O z 26.5 35.3 40.6 67
Maximum Line Length F t / m 66/20 66/20 83/25 83/25
Maximum Height F t / m 33/10 33/10 50/15 50/15
20
20
20
25
1U09TE1VHA 1U12TE1VHA 1U18TE2VHA 1U24TE2VHA
AW09TE1VH*
AW12TE1VH* AW18TE2VH*
AW24TE2VH*
