Haier AS53PDDHRA [8/12] Pinnacle specifications
![Haier AS53PDDHRA [8/12] Pinnacle specifications](/views2/1812501/page8/bg8.png)
ModelsModels
Warranty*
Self-Clean Voice Control
Coanda
Plus Airflow
Coanda
Anti-Bacterial
Silver ion coating
Dry Function Whispering Air
24 Hours Timer
Sleep Mode
COOL
DC Inverter
Weekly TimerSavings EER
Turbo Cooling
SmartHQ™ app Wireless
Remote Contoller
Easy Installation ReliabilityEasy
Maintenance
Auto Restart
Anti-Corrosion
Anti Corrosion
SAgSAg
Outdoor Unit
1U26MACFRA 1U35MACFRA 1U53RACFRA 1U71RACFRA
Indoor Unit
UV Protect
Z
Z
Z
Specifications
ZERL Zoned Energy Rating Label - residential air conditioning star rating based on GEMS 2019 Determination.
Rated Load Amps (RLA) is based on nominal conditions. Use Maximum Circuit Amps (MCA) for power supply infrastructure sizing, etc.
Test conditions are based on AS/NZS3823.1.1.
Model
Indoor
Outdoor
AS26PBDHRA
1U26MADFRA
AS35PBDHRA
1U35MADFRA
AS53PDDHRA
1U53WADFRA
AS71PDDHRA
1U71WADFRA
ZERL Star Rating
Cooling: Hot/Average/Cold 4.5/4.0/4.0 3.5/3.5/3.5 3.5/3.0/3.5 2.5/2.5/2.5
Heating: Hot/Average/Cold 3.5/3.0/2.0 3.0/2.5/1.5 3.0/2.5/2.0 2.5/2.0/1.5
2.5 (1.2 ~ 3.0) 3.5 (1.2 ~ 3.9) 5.0 (1.3 ~ 5.5) 7.0 (1.8 ~ 7.5)
3.0 (1.2 ~ 3.6) 3.7 (1.3 ~ 4.3) 5.5 (1.4 ~ 6.2) 7.6 (1.8 ~ 8.2)
0.56 (0.23 ~ 1.18) 0.92 (0.30 ~ 1.4) 1.30 (0.2 ~ 1.9) 2.12 (0.3 ~ 2.6)
0.68 (0.21 ~ 1.5) 1.0 (0.29 ~ 1.7) 1.4 (0.2 ~ 2.5) 2.27 (0.3 ~ 2.7)
Capacity (kW)
Rated (Minimum ~ Maximum)
Cooling
Heating
Power input (kW)
Rated (Minimum ~ Maximum)
Cooling
Heating
5.494 / 5.053 / 5.2686.068 / 5.519 / 5.674 5.212 / 4.908 / 5.108 4.419 / 4.196 / 4.367
6.538 / 6.614 / 7.046 5.941 / 6.105 / 6.561 5.568 / 5.687 / 6.080 4.706 / 4.816 / 5.148
5.457 / 4.505 / 3.788 4.816 / 4.046 / 3.452 4.667 / 4.129 / 3.595 4.090 / 3.627 / 3.196
4.493 / 4.917 / 4.263 4.841 / 4.379 / 3.844 4.675 / 4.350 / 3.889 4.097 / 3.818 / 3.445
Cooling Seasonal Performance
(Hot/Average/Cold Climate)
Heating Seasonal Performance
(Hot/Average/Cold Climate)
Residential
Commercial
Residential
Commercial
EER/AEER 4.46/4.40 3.80/3.76 3.85/3.82 3.30/3.29
COP/ACOP 4.41/4.36 3.70/3.66 3.93/3.91 3.35/3.29
Electrical
Rated Load Amps (Amp)
Cooling 2.5 4.1 6.0 9.5
Heating 2.9 4.4 6.4 10.0
MCA Max Circuit Amps (Amp)
7.2 8.1 11.0 12.2
Breaker size (Amp) 10 10 16 20
Power cable connection location Outdoor
Power supply (Ph/V/Hz) 1/220-240/50
Refrigeration
Refrigerant Type R32
Refrigerant Factory Charge (kg) 0.80 0.84 1.02 1.10
Pipe Size (mm (Inch))
Liquid Line 6.35mm (1/4”)
Suction Line 9.52mm (3/8”) 12.7mm (1/2”)
Pipe length (Max)
Maximum Height Difference (m)
15 20
10 15
Pre-charged up to a Length (m) 7
Additional Refrigerant (grams/m) 20
Indoor Unit
Model
Net dimension (mm) W/D/H 805/200/292 805/200/292 970/220/320 970/220/320
Net weight (kg) 11.6 11.68.78.7
Air Circulation H/M/L (L/S)
Cooling 155/133/97 180/152/125 260/228/195 305/260/220
Heating 150/130/95 175/145/120 225/198/168 260/220/190
Sound Pressure Level (dBA) H/M/L 40/36/32 40/36/32 47/43/37 48/44/38
Remote YR-HE
Outdoor Unit
Model
Net dimension (mm) W/D/H 800/275/553 890/340/705800/275/553 890/340/705
Net weight (kg) 29.7 30.0 43.2 43.5
Compressor Type Rotary
Sound Pressure Level (dBA) 51 53 47 48
Sound Power Level (dBA) 59 63 66 67
Operating Temperature Range
Outdoor (Min ~ Max) Cooling -10°C to +46°C
Outdoor (Min ~ Max) Heating -15°C to +24°C
Pinnacle specifications
1U26MADFRA 1U35MADFRA 1U53WADFRA 1U71WADFRA
AS26PBDHRA AS35PBDHRA AS53PDDHRA AS71PDDHRA
