Haier 1U26MADFRA [26/28] Installation procedure
![Haier 1U26MADFRA [26/28] Installation procedure](/views2/1812509/page26/bg1a.png)
20 30
15 2.5
201
30
2.5
25
25
20
1
ceramic type of AC 250V, T25A.
The explosion-proof breaker of the air conditioner should be all-pole switch. The distance between its two contacts should not be no
A explosion-proof breaker must be installed.
24
1U53WADFRA
09K
12K
18K
Model
Connecting wiring
Power cable
3G1.5mm²
1U26MADFRA
1U35MADFRA
-mod:18-24:3G2.5mm²
local
4G1.5mm²
4G1.5mm²
3G1.5mm²
3G2.5mm²
1U71WADFRA
Power cable:
-mod 09-12:
3G1.5mm
2
4G1.5mm
2
POWER
1U09MADFRA
1U12MADFRA
1U26MADFRA
1U35MADFRA
1U18WADFRA
1U24WADFRA
1U53WADFRA
1U71WADFRA
4G1.5mm²
24K
4G1.5mm²
3G2.5mm²
30
2.5
25
25
20
1
Power cable:
4G1.5mm
2
POWER
Installation Procedure
Electrical Wiring
WARNING!
DANGER OF BODILY INJURY OR DEATH
• TURN OFF ELECTRIC POWER
AT
CIRCUIT BREAKER OR POWER SOURCE BEFORE MAKING ANY ELECTRIC
CONNECTIONS.
• GROUND CONNECTIONS MUST BE COMPLETED BEFORE MAKING LINE VOLTAGE CONNECTIONS.
Precautions for Electrical wiring
• Electrical wiring work should
be
conducted only by authorized personnel.
•
Do
not connect more than three wires to the terminal block. Always use round type crimped terminal lugs with insulated
grip
on
the ends
of
the wires.
• Use copper conductor only.
Selection
of
size
of
power supply and interconnecting wires
Select wire sizes and circuit protection from table below. (This table shows 20 m length wires with less than 2% voltage
drop.)
I~
Circuit breaker
Power source
Earth leakage breaker
Phase
Switch breaker Overcurrent protector
wire size
Switch Leak
(minimum)
I
(A) rated capacity (A)
(mm
2
)
breaker(A) current(mA)
• If the supply cord
is
damaged, it must
be
replaced by the manufacturer or itsservice agent or a similar qualified person.
• If the fuse
of
control box
is
broken, please change it with the
• The wiring method should
be
in
line with the local wiring standard.
• All the cables shall have got the authentication certificate. During installation, when the connecting cables
break off, it must
be
assured that the grouding wire
is
the last one to
be
broken off .
•
less than 3mm. Such means for disconnection must
be
incorporation
in
the fixed wiring.
• The distance between its two terminal blocks
of
indoor unit and outdoor unit should not
be
over 5m. If exceeded, the
diameter
of
the wire should
be
enlarged according to the local wiring standard .
•
Wiring procedure
1) Remove set screws on the side before taking off the front panel toward the direction.
2) Connect wires to the terminal block correctly and fix the wires with a wire clamp equipped nearby the terminal block.
3) Route the wires
in
a proper way and penetrate the wires through the opening for electrical wiring
on
the side panel.
WARNING:
INTERCONNECTING WIRES MUST
BE
WIRED ACCORDING
TO
FIGURE
BELOW
INCORRECT WIRING MAY CAUSE
EQUIPMENT DAMAGE.
