Haier AS26FBBHRA [9/12] F series flexis specifications

9

Indoor AS26FBBHRA AS35FBBHRA AS53FEBHRA AS71FEBHRA AS82FFAHRA

Outdoor 1U26JACFRA 1U35JACFRA 1U53RABFRA 1U71SABFRA 1U82SAAFRA

Capacity (kW)

Cooling 2.65 (1.5 - 3.2) 3.4 (1.3 - 4) 5.1 (1.5 - 6.7) 7.1 (1.9 - 8.4) 8.2 (2.4 - 9.0)

Heating 3.3 (1.6 - 3.8) 3.8 (1.6 - 4.3) 5.7 (1.6 - 7.7) 7.6 (2 - 10.2) 9.0 (2.7 - 11.0)

Power input (kW)

Cooling 0.5 (0.28 ~ 1.1) 0.78 (0.29 ~ 1.3) 1.16 (0.36 ~ 2.1) 1.71 (0.54 ~ 2.6) 2.27 (0.65 ~ 2.9)

Heating 0.65 (0.4 ~ 1.4) 0.79 (0.4 ~ 1.4) 1.26 (0.4 ~ 2.5) 1.89 (0.64 ~ 2.9) 2.5 (0.67 ~ 3.6)

Heating 5.5 5.0 4.5 3.5 3.0

Electrical

Running current (A)

Cooling 2.33 3.57 5.20 7.51 10.10

Heating 3.00 3.58 5.53 8.24 11.10

Max Running current (A)

Cooling 4.9 5.7 9.4 11.4 15.0

Heating 6.1 6.1 11.0 12.6 18.0

Power cable connection location

Outdoor Outdoor Outdoor Outdoor Outdoor

Liquid / Suct 6.35 / 9.52 6.35 / 9.52 6.35 / 12.7

6.35 / 12.7

6.35 / 15.88

Refrigerant Charge (kg)

1.10 1.20 1.30

Pipe length (Min ~ Max)

Maximum Height Dierence (m)

Additional Refrigerant (grams/m)

INDOOR UNIT

Model

AS26FBBHRA AS35FBBHRA AS53FEBHRA AS71FEBHRA AS82FFAHRA

Net dimension (mm)

W/D/H 870 x 196 x 301 870 x 196 x 301 1115×230×337 1115×230×337 1342 x 275 x 365

Net weight (kg)

10.1 10.1 13.0 13.0 21.0

OUTDOOR UNIT

Model

1U26JACFRA 1U35JACFRA 1U53RABFRA 1U71SABFRA 1U82SAAFRA

Net dimension (mm)

W/D/H 820×338×614 820×338×614 890×353×697 920×385×762 920 x 385 x 762

Net weight (kg)

40.6 40.6 49.0 54.0 60.0

Compressor Type

Cooling -10°C to +46°C -10°C to +46°C -10°C to +46°C -10°C to +46°C -10°C to +46°C

Outdoor (Min ~ Max)

Heating -15 °C to +24 °C -15 °C to +24 °C -15 °C to +24 °C -15 °C to +24 °C -15 °C to +24 °C

Rating Conditions (AS / NZS 3823). Cooling – Indoor: 27°C DB, 19°C WB. Outdoor: 35°C DB. Heating – Indoor: 20°C DB Outdoor: 7°C DB, 6°C WB (DB: Dry Bulb ; WB: Wet Bulb)

F series (Flexis) specications
